SPEC-2750 (J - June 2014)


>> Download SPEC-2750 (J - June 2014) documenatation <<

Text preview - extract from the document
Model 2750 Multimeter/Switch System
DC CHARACTERISTICS1
CONDITIONS: MED (1 PLC)2 or 10 PLC or MED (1 PLC) with Digital Filter of 10
                                                                                   INPUT              ACCURACY: (ppm of reading + ppm of range)
                                                        TEST CURRENT RESISTANCE OR                    (ppm = parts per million) e.g., 10ppm = 0.001%)      TEMPERATURE
                                                        5% OR BURDEN            OPEN CKT.              24 Hour4           90 Day              1 Year        COEFFICIENT
                                                                                            3
FUNCTION                   RANGE        RESOLUTION         VOLTAGE              VOLTAGE                 23
