Image preview - the first page of the document



>> Download AD548 documenatation <<

Text preview - extract from the document

a                                                                                                      Precision, Low Power
                                                                                                               BiFET Op Amp
                                                                                                                    AD548
   FEATURES                                                                                       CONNECTION DIAGRAMS
   Enhanced Replacement for LF441 and TL061                                                       Plastic Mini-DIP (N) Package
   DC Performance:                                                                                             and
     200 A max Quiescent Current                                                                        SOIC (R)Package
     10 pA max Bias Current, Warmed Up (AD548C)
     250 V max Offset Voltage (AD548C)
     2 V/ C max Drift (AD548C)                                                                 OFFSET NULL 1                8 NC
     2 V p-p Noise, 0.1 Hz to 10 Hz                                                              INVERTING 2                7 V+
                                                                                                     INPUT
   AC Performance:                                                                            NONINVERTING 3                6 OUTPUT
     1.8 V/ s Slew Rate                                                                              INPUT
     1 MHz Unity Gain Bandwidth                                                                         V
