Image preview - the first page of the document



>> Download LSK389_ documenatation <<

Text preview - extract from the document

                                                                                                 LSK389
                                                                                      ULTRA LOW NOISE
                                                                                      MONOLITHIC DUAL
                                                                                  N-CHANNEL JFET AMPLIFIER

FEATURES
ULTRA LOW NOISE                              en = 0.9nV/Hz (typ)
TIGHT MATCHING                               IVGS1-2I = 20mV max
HIGH BREAKDOWN VOLTAGE                        BVGSS = 40V max
HIGH GAIN                                        Gfs = 20mS (typ)
LOW CAPACITANCE                                      25pF typ
IMPROVED SECOND SOURCE REPLACEMENT FOR 2SK389
ABSOLUTE MAXIMUM RATINGS1
@ 25
