Image preview - the first page of the document



>> Download LSK489 documenatation <<

Text preview - extract from the document

                                                                                                 LSK489
                                                                            LOW NOISE LOW CAPACITANCE
                                                                                 MONOLITHIC DUAL
                                                                             N-CHANNEL JFET AMPLIFIER


 FEATURES
 ULTRA LOW NOISE                                en = 1.8nV/Hz
 LOW INPUT CAPACITANCE                             Ciss = 4pF



Features                                Benefits                                            Applications
      Reduced Noise due                        Tight differential voltage match vs.                Wide band differential Amps
      to process improvement                   current                                             High speed temperature
      Monolithic Design                        Improved op amp speed settling time                 compensated single ended input
      High slew rate                           accuracy                                            amplifier amps
      Low offset/drift voltage                 Minimum Input Error trimming error                  High speed comparators
      Low gate leakage lgss & lg               voltage                                             Impedance Converters
      High CMRR 102 dB                         Lower intermodulation distortion



Description
The LSK 489 series of high performance monolithic dual JFETs features extremely low noise, tight offset voltage and low drift
over temperature specifications, and is targeted for use in a wide range or precision instrumentation applications. This series has
a wide selection of offset and drift specifications. The SST series SO-8 package provided ease of manufacturing and the
symmetrical pinout prevents improper orientation. The SO-8 package is available with tape and reel options for compatibility with
automatic assembly methods. (See packaging data)




 ABSOLUTE MAXIMUM RATINGS1
 @ 25
