Image preview - the first page of the document



>> Download h11av1 documenatation <<

Text preview - extract from the document

                                                 PHOTOTRANSISTOR OPTOCOUPLERS



H11AV1-M                           H11AV1A-M                           H11AV2-M                          H11AV2A-M

                         PACKAGE OUTLINE                                                         SCHEMATIC

                                                                                            1                          6


                                                                                            2                          5
           6
                                             6
                                                                                            3      NC                  4
                      1
       H11AV1S-M, H11AV2S-M
                                                      1                                         PIN 1. ANODE
                                             H11AV1-M, H11AV2-M                                     2. CATHODE
                                                                                                    3. NO CONNECTION
                                                                                                    4. EMITTER
                                                                                                    5. COLLECTOR
                                                                                                    6. BASE



                          6

                                1
                     H11AV1A-M, H11AV2A-M




DESCRIPTION
The general purpose optocouplers consist of a gallium arsenide infrared emitting diode driving a silicon phototransistor in a 6-pin
dual in-line white package.
