Image preview - the first page of the document
>> Download 447-2,0 documenatation <<
Text preview - extract from the document
Racks and Rack Mount Kits
Instrument Single Single Dual Type of
Model Number Fixed Slide1 Fixed Mount
197A 480 485 580 1010 1017 Shelf
428 486 487 776 2000 Series 4288-22 Side
2182 2300 Series 2400 Series 2500 Series 4288-1 4288-43 Shelf
2700 6430 6485 6514 6517A 7001 4288-54 Shelf
2750 4288-7 Rear bracket
220 224 230 230-1
1019A-2 Bracket w/handles
263 595 614 617 1019A-1
4288-43 Shelf
740 775A 6512
Model 248-RMK-1 Fixed Rack Mount Kit: 236 237 238 1938 1939 Bracket w/handles
Enables rack mounting of one Model 248. 228A 2288 2289A Bracket w/handles
590 2288-1G
For use with: 248 595/230-1 1019A-2G Bracket w/handles
HEIGHT: 89mm (31/2 in). 248 248-RMK-1 248-RMK-2 Side
Racks and rack mount kits
707A Included 7079 Side
708A Included Side
776 7768 4288-54 Side
7002 7002-RMK-1 7002-RMK-2 Bracket w/handles
3300 Series 3900-1 3900-2 Side
1 Slide rack mount kits are not compatible with equipment cabinet Models 8000-10, 8000-14 and 8000-17.
2 Model 4288-2 mounts any two of the listed models, except 776.
3 Model 4288-4 mounts: ANY ONE plus ANY ONE
220 224 230 230-1 263 428 486 487 2000 Series
595 614 617 740 775A 2182 2300 Series 2400 Series 2500 Series
2700 6430 6485 6514 6517A 7001
4 Model 4288-5 mounts any one or two of the listed models on a shelf-type mount.
Model 248-RMK-2 Fixed Rack Mount Kit: 1019A-1
Enables rack mounting of two Model 248s side by
side.
For use with: 248
HEIGHT: 89mm (31/2 in).
Model 1017: Similar to Model 1010 but mounts
any two Models 197A and 580. 1019A-2
For use with: 197A, 580
DIMENSIONS: 132mm high ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
