Image preview - the first page of the document
>> Download 4671-2,0 documenatation <<
Text preview - extract from the document
Connectors, Adapters, and Tools
MODEL NAME USE WITH:
213-CON Analog Output Connector 213
237-BAN-3 Triax to Banana Plug 7072, 7072-HV 7172, 2001, DMMs
,
237-BNC-TRX 3-Lug Female Triax to Male BNC Connector with 237, 6517A, 7078-TRX cables
guard disconnected
237-TRX-BAR 3-Lug Triax Female to Female (Barrel) Adapter Triax interconnect
237-TRX-NG Triax Male-Female Adapter with guard disconnected 236, 237, 238, 7072, 7072-HV 7172
,
237-TRX-T 3-Slot Male to Dual 3-Lug Female Triax Tee Adapter 7072, 7072-HV 7172, 7078-TRX cables
,
237-TRX-TBC 3-Lug Female Triax Bulkhead Connector 7072, 7072-HV 7172, 7078-TRX cables
,
2182-325A Silver Solder for use with 2182-KIT 2182
2182-KIT Low-Thermal Connector with Strain Relief (LEMO) 2182, SC-93
2188 Low-Thermal Calibration Shorting Plug 2182
2286 Safety Output Assembly 228A
Model 213-CON Analog Output Connector:
Connectors, adapters, and tools
2499-DIGIO Digital I/O Expansion Module SourceMeter Instruments
Quick disconnect analog output connector for
2500INT-SMA SMA Connector 2500INT Integrating Sphere
Model 213 Quad Voltage Source. Screw terminals
2500INT-SMA-FC/PC FP/PC Connector Connector 2500INT Integrating Sphere
provided for connection of test leads.
2500INT-SMA-FC/APC FP/APC Connector 2500INT Integrating Sphere
4804 Male BNC to 2-Lug Female Triax Adapter 485 For use with: 213
4851 BNC Shorting Plug 230-1, 7077
5904 20nF/20mS Adapter (not calibrated to mainframe) 590
5951 Remote Input Coupler Model 82-WIN
6012 Triax to UHF Adapter 220, 224, 617
6146 2-Lug Triax Tee Adapter 617
6147 2-Slot Male Triax to Female BNC Adapter 220, 224, 617
6167 Guarded Input Adapter 220, 224
Item shipped may
6171 3-Slot Male to 2-Lug Female Triax Adapter 6011, 7024 vary from model
6172 2-Slot Male to 3-Lug Female Triax Adapter 220, 224, 617 pictured here.
6176 Adapter Kit: Includes Models 6146, 6147, 6171, 6172, 220, 224, 617
7078-TRX-BNC, 4804
6424 BNC Input Adapter 642
Model 237-BAN-3 Triax to Banana Plug: Triax
7001-PNL Metal Plate 7001
cable center conductor terminated in a safety
7011-KIT-R Female 96-Pin Connector Kit 7011-C, 7012-C, 7013-C, 7015-C, 7018-C
banana plug (guard and shield open). For connect-
7011-MTR Bulkhead Mount 96-Pin Male Connector 7011-KIT-R, 7011-C, 7012-C, 7013-C, 7015-C, 7018-C
ing DMMs and other banana jack instruments to a
7011-ST Extra Screw Terminal Board 7011-S
matrix or fixture.
7012-ST Extra Screw Terminal Board 7012-S For use with: 7072, 7072-HV, 7172, DMMs
7013-ST Extra Screw Terminal Board 7013-S
7014-ST Extra Screw Terminal Board 7014
7015-ST Extra Screw Terminal Board 7015-S
7018-ST Extra Screw Terminal Board 7018-S
7023 2-Lug Female Triax Bulkhead Connector 6011, 7024
7074-CIT Contact Extraction Tool 7074-KIT, 7074-MTR, 7152-KIT, 7152-MTR
7074-HCT Hand Crimping Tool 7074-KIT, 7074-MTR, 7152-KIT, 7152-MTR
7074-KIT 75-Pin Mass Terminated Plug w/Contacts 7074-D, 7074-MTR
7074-MTR 75-Pin Mass Terminated Receptacle w/Contacts 7074-D, 7074-KIT, 7074-MTC
7074-RTC Relay Test Shorting Connector 7074-D
Model 237-BNC-TRX: Male BNC to 3-lug female
7078-CIT Contact Insertion/Extraction Tool 7078-KIT, 7078-MTR, 7152-KIT, 7152-MTR, 7169-KIT,
triax adapter (guard disconnected). Terminates
7169-MTR triax cable in BNC plug. High voltage rating for use
7078-HCT Hand Crimping Tool for 7078-KIT, 7169-KIT 7078-KIT, 7169-KIT with 237 and 7072-HV.
INSTRUMENT ACCESSORIES
7078-KIT Connector Kit 7071, 7071-4, 7074-D, 7078-MTR For use with: 237, 6517A, 7078-TRX Cables
7078-MTR Mass Terminated Receptacle, Bulkhead Mount 7078-KIT, 7078-MTC
7078-TRX-BNC 3-Slot Male Triax to BNC Adapter 486, 487, 4801, 6514, 6517A, 7072, 7072-HV
7078-TRX-GND 3-Slot Male Triax to BNC Adapter (guard removed) 236, 237, 238, 4801, 6517A, 7051, 7072, 7072-HV
7078-TRX-TBC 3-Lug Female Triax Bulkhead Connector w/Cap 7078-TRX cables
7152-HCT Hand Crimp Tool for 7152-KIT, 7152-MTR 7152-KIT, 7152-MTR
7152-KIT 6-Position M-Series Plug w/Contacts 7152, 7152-MTR
7152-MTR 6-Position M-Series Receptacle w/Sockets 7152, 7152-KIT, 7152-MTC-2, 7152-MTC-10
7164-KIT 50-Pin Mass Terminated Connector 7164-D, 7164-M, 7164-MTR
7164-MTR 50-Pin Mass Terminated Bulkhead Mount Receptacle 7164-D, 7164-M, 7164-MTC-10
7169-KIT 20-Pin Mass Terminated Connector 7169A Model 237-TRX-BAR: 3-lug triax barrel for use
7169-MTR Mass Terminated Bulkhead Mount Receptacle 7169A, 7169-MTC-3 with triax interconnect.
For use with: Triax interconnect
1.888.KEITHLEY (U.S. only)
www.keithley.com
A G R E A T E R M E A S U R E O F C O N F I D E N C E
Connectors, Adapters, and Tools
MODEL NAME USE WITH:
7755 50 Feed-Through Terminator RG 58 Cable, 776
7788 50-Pin D Subconnector Kit 7703, 7705, 77XX, modules with D sub connectors
8610 Low Thermal Shorting Plug 2000, 2001, 2002, 2010
8680 RTD Probe Adapter 2001, 2002, 2010
BG-18 Dual Banana to BNC Coaxial Adapter 230, 20XX Series, 24XX Series, 2700, 2750
CAP-18 Protective Shield/Cap BNC, 2-lug triax connectors
CAP-31 Protective Shield/Cap 3-lug triax connectors
CS-141 2-Lug Male Triax Cable Mount Connector SC-22 Cable
CS-400 DB25 Male Solder Cup CA-126-1 cable, 213
CS-440 Bulkhead Connector 220, 263, fixtures Model 2188 Low-Thermal Calibration
CS-458 Interlock Connector Kit 6517-ILC-3 Shorting Plug: A low-resistance, low-thermal
CS-565 BNC Barrel BNC interconnect shorting plug required to calibrate the Model 2182
Connectors, adapters, and tools
CS-631 3-Lug Male Triax Cable Mount Connector SC-22 Cable Nanovoltmeter. Made of a LEMO connector with its
CS-846 Screw Terminal Test Lead Connector 230X, 2510, 2510-AT pin connectors shorted together using copper wire
CS-970 High Voltage Bulkhead Connector 248, 248-SHV Cable and Sn/Ag4 silver solder.
For use with: 2182
Model 237-TRX-NG: 3-slot triax to 3-lug female Model 237-TRX-TBC: 3-lug female triax bulkhead
triax (guard removed) for non-guarded measure- connector with cap for assembly of custom panels Model 2286 Safety Output Connector: Slides
ments. High voltage rating for use with 237, and interface connections. High voltage rating for into Model 228 or 228A Current/ Voltage Source to
7072-HV, etc. use with 237, 7072-HV, etc. Uses miniature coax assure that the active outputs are not accessible.
cable, not triax cable, at soldered end. Bulkhead is Outputs are disconnected when the safety card is
For use with: 236, 237, 238, 7072, 7072-HV,
7172 outer shield. removed from the instrument. The connector pro-
vides screw terminals for Force and Sense on both
For use with: 7072, 7072-HV, 7172, 7078-TRX
High and Low outputs as well as separate Current
cables
Monitor and Modulation Input connections.
Model 2182-325A: Silver solder for making con- For use with: 228A
nections in experiments with the Model 2182. 20 ft
roll.
For use with: 2182
Model 237-TRX-T: 3-slot male to dual 3-lug
female triax tee adapter for use with 7078-TRX
cables and 7072/7072-HV Semiconductor Matrix
INSTRUMENT ACCESSORIES
Cards. High voltage rating for use with Model 237
SMU.
For use with: 7072, 7072-HV, 7172, 7078-TRX
cables
Model 2499-DIGIO: Digital I/O expansion mod-
ule that plugs onto the DB-9 connector of a
Model 2182-KIT Low-Thermal Connector SourceMeter. Expands the three digital I/O lines of
with Strain Relief: Connector kit for building a the SourceMeter to 16 lines. The SOT, EOT/BUSY,
custom input cable for the Model 2182 5V, GND, and Interlock signals are passed through.
Nanovoltmeter. Includes a low-thermal (LEMO) For use with: SourceMeter Instruments
connector and a strain relief.
For use with: 2182, SC-93
1.888.KEITHLEY (U.S. only)
www.keithley.com
A G R E A T E R M E A S U R E O F C O N F I D E N C E
Connectors, Adapters, and Tools
Model 4851: BNC shorting plug.
For use with: 230-1, 7077
Model 2500INT-SMA: SMA connector for 2500- Model 6146 2-Slot Triax Tee Adapter: To con-
INT Integrating Sphere. nect multiple inputs to Model 617; allows easy
connection of external feedback elements.
For use with: 2500-INT
For use with: 617
Connectors, adapters, and tools
Model 5904: 20nF/20mS adapter. Extends range Model 6147 2-Slot Triax to BNC Adapter:
of Model 590/100k. Permits using Models 220, 224, and 617 with acces-
Model 2500INT-FC/PC: FC/PC connector for sories having BNC connectors.
For use with: 590
2500-INT Integrating Sphere.
For use with: 220, 224, 617
For use with: 2500-INT
Model 5951 Remote Input Coupler: Includes Model 6167 Guarded Input Adapter: Reduces
Model 2500INT-FC/APC: FC/APC connector for the remote input coupler, five 1.2m low noise BNC effective cable capacity by driving the inner shield
2500-INT Integrating Sphere. cables (Model 4801), two 1m IEEE-488 cables of the triax cable at Guard potential. For use with
(Model 7007-1), one 2m shielded IEEE-488 cable Models 220 and 224. 2-slot triax female to 2-slot
For use with: 2500-INT
(Model 7007-2), and three 0.6m RG-58C BNC-to- triax male.
BNC cables (Model 7051-2).
For use with: 220, 224
For use with: Model 82-WIN
INSTRUMENT ACCESSORIES
Model 4804: 2-slot male BNC to 2-lug female triax
adapter. Used to adapt triax cables to 2-lug BNC
input connectors.
Model 6171: 3-slot male to 2-lug female triax
For use with: 485 adapter. Adapts 7024 and 6011 cables to 3-lug triax
Model 6012 2-Slot Triax to UHF Adapter: Per- input connectors.
mits using Models 220, 224 and 617 with all
For use with: 6011, 7024
Keithley electrometer accessories having UHF type
connectors.
For use with: 220, 224, 617
1.888.KEITHLEY (U.S. only)
www.keithley.com
A G R E A T E R M E A S U R E O F C O N F I D E N C E
Connectors, Adapters, and Tools
Model 7012-ST: Extra quick disconnect screw ter-
Model 6172: 2-slot male to 3-lug female triax minal board. One 7012-ST is included with each
adapter. For use in adapting Models 220, 224, and 7012-S.
617 inputs to 3-slot triax plugs. For use with: 7012-S
Connectors, adapters, and tools
For use with: 220, 224, 617
Model 7011-KIT-R: 96-pin female DIN connector
with solder eyelets and strain relief. This kit can be
used for assembly of custom cables to connect
with the connectors on the 7011-C, 7012-C, 7013-
C, 7015-C, and 7018-C switch cards. Also connects
with the 7011-MTR bulkhead mount male
connector.
For use with: 7011-C, 7012-C, 7013-C, 7015-C,
7018-C Model 7013-ST: Extra quick disconnect screw ter-
minal board. One 7013-ST is included with each
Model 6176 Adapter Kit: Consists of 6146, 6147, 7013-S.
6171, 6172, 7078-TRX-BNC, and 4804 in a compart- For use with: 7013-S
mentalized box. Use when interfacing BNC, 2-lug
triax, and/or 3-lug triax instrumentation.
For use with: 220, 224, 617
Model 7011-MTR: 96-pin male DIN connector
with solder eyelets for bulkhead mount. Connects
with the 7011-KIT-R and the 7011-MTC-2.
For use with: 7011-KIT-R, 7011-C, 7012-C,
7013-C, 7015-C, 7018-C
Model 7014-ST: Extra quick disconnect isother-
mal screw terminal board with cold junction sen-
sor. One 7014-ST is included with each 7014.
Model 6424: BNC adapter for use with Model For use with: 7014
642. lt is the most convenient connection method,
limited by currents generated in the flexible
cabling.
For use with: 642
Model 7011-ST: Extra quick disconnect screw ter-
INSTRUMENT ACCESSORIES
minal board. One 7011-ST is included with each
7011-S.
For use with: 7011-S
Model 7015-ST: Extra quick disconnect screw ter-
minal board. One 7015-ST is included with each
7015-S.
For use with: 7015-S
Model 7001-PNL: Metal plate used to cover an
empty card slot on the rear panel of a Model 7001.
For use with: 7001
1.888.KEITHLEY (U.S. only)
www.keithley.com
A G R E A T E R M E A S U R E O F C O N F I D E N C E
Connectors, Adapters, and Tools
Model 7018-ST: Extra quick disconnect screw ter-
minal board. One 7018-ST is included with each
7018-S.
For use with: 7018-S Model 7078-CIT: Contact insertion and extrac-
tion tool for assembly and maintenance of 7078-
Connectors, adapters, and tools
Model 7074-KIT: 75-pin plug assembly with strain
MTC cables and connectors.
relief and 80 contacts for assembly of custom cable
and harnesses compatible with 7074-D multiplexer For use with: 7078-KIT, 7078-MTR, 7152-KIT,
card and 7074-MTR mass terminated receptacle. 7152-MTR, 7169-KIT, 7169-MTR
For use with: 7074-D, 7074-MTR
Model 7023 2-Lug Triax Bulkhead Mount
Connector: Chassis mount connector mates with
Keithley accessory cables 6011 and 7024 series.
For use with: 6011, 7024
Model 7078-HCT: Contact crimping pliers
for assembly of cables and connectors using
7078-MTR or 7078-KIT.
Model 7074-MTR: 75-pin bulkhead mount recep-
tacle with 80 contacts for custom interface and For use with: 7078-KIT, 7169-KIT
patch panels compatible with 7074-MTC and
7074-KIT.
Model 7074-CIT: Contact extraction tool for For use with: 7074-D, 7074-KIT, 7074-MTC
removal of contacts from 7074-MTC cables and
connectors.
For use with: 7074-KIT, 7074-MTR, 7152-KIT,
7152-MTR
Model 7078-KIT: 38-pin plug assembly with strain
Model 7074-RTC: Relay test connector. The 7074- relief and 40 contacts for assembly of custom cable
RTC adapts column inputs with jumper intercon- and harnesses compatible with Model 7071 8◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
