Image preview - the first page of the document



>> Download 445-1,0 documenatation <<

Text preview - extract from the document

                                INSTRUMENT ACCESSORIES

    Function and Scanning Options
    FUNCTIONS AND SCANNING OPTIONS SELECTOR GUIDE
      MODEL                                   NAME                                                  USE WITH:
      2000-SCAN                               10-Channel Scanner Card                               2000, 2001, 2002, 2010*
      2001-SCAN                               10-Channel Scanner Card                               2000, 2001, 2002, 2010*
      2001-TCSCAN                              9-Channel Scanner Card                               2000, 2001, 2002, 2010
      2000-SCAN-20**                          20-Channel Scanner Card                               2000-20
      6521                                    10-Channel Scanner Card                               6517A
      6522                                    10-Channel Scanner Card                               6517A
      * NOTE: The 2000-SCAN will operate in all four models as a 10-channel scanner, but does not have the two high-speed solid
        state channels required by the 2001 and 2002 Ratio and Delta modes. The 2001-SCAN will operate as a 10-channel scan-
        ner in all four models, but the 2000 and 2010 cannot utilize the two high-speed solid state channels.
     ** Replacement card for 2000-20 DMM/Scanner combination. See page 46 for specifications.




    Model 2000-SCAN: A 10-channel scanner                          Model 2001-SCAN: A 10-channel scanner                          Model 2001-TCSCAN: Provides nine chan-
    that installs into the option slot on any 2000                 containing eight relay inputs and two solid                    nels of cold-junction compensated temper-
    Series DMM. Multiplex one of ten 2-pole or                     state inputs. Multiplex one of ten 2-pole or                   ature measurements and/or voltage, resis-
    one of five 4-pole signals into the Model                      one of five 4-pole signals into the Model                      tance, and frequency measurements when
    2000 or 2010 and/or any combination of 2-                      2000, 2001, 2002, or 2010 DMM and/or any                       installed in a 2000, 2001, 2002, or 2010
    or 4-pole signals. Contact potential is typi-                  combination of 2- or 4-pole signals. Two                       DMM. (See specific instrument for TC types
    cally less than 500nV per contact pair (1
