Image preview - the first page of the document



>> Download 2220G_2230GPowerSuppliesAppCards documenatation <<

Text preview - extract from the document

    Application Overview:
    Using Multiple-Channel Power Supplies for Maximum Flexibility


     Multiple-Channel DC Power Supplies
     Most devices require multiple DC power supplies operating at different
     voltages to power all the analog and digital circuit sub systems. During
     development and testing, a number of single-channel power supplies can
     be used to power up each circuit section. Alternatively, a multiple-channel
     power supply could meet all your requirements and reduce the number of
     instruments needed. A single power supply will also take up less precious
     bench space or test rack space.

     With Keithley multi-channel power supplies, there are no compromises
     compared with using two or more single-channel supplies. All the channels
     in Keithley multiple-channel power supplies can be controlled independently
     and are isolated just as if they were individual supplies. Each channel's
     output is programmable, and each channel's voltage output and load current
     measurements are displayed simultaneously. Furthermore, each channel
     has remote sensing to ensure that the required voltage is accurately applied
     to the load. When a number of supplies are needed, consider the flexibility
     and convenience of a multi-channel power supply.
