Image preview - the first page of the document



>> Download 071317000(2290-PM-200) documenatation <<

Text preview - extract from the document

                                                                           Model 2290-PM-200
Keithley Instruments, Inc.
28775 Aurora Road
                                                          Protection Module User's Guide
Cleveland, Ohio 44139
1-888-KEITHLEY
http://www.keithley.com



Model 2290-PM-200
Description
   The Model 2290-PM-200 protection module (PM) is a stand-alone module that protects certain lower-voltage
   source-measure units (SMUs) that are part of a testing configuration from damage by voltage sources that are
   greater than 220 V.
                                          Figure 1: Model 2290-PM-200




   The protection module is designed for use with the following lower-voltage SMUs:
