Image preview - the first page of the document
>> Download 707B-903-01 documenatation <<
Text preview - extract from the document
Models 707B and 708B Quick Start Guide
Observe the following safety precautions before using this product and any associated Service personnel are trained to work on live circuits, perform safe installations, and
instrumentation. Although some instruments and accessories would normally be used repair products. Only properly trained service personnel may perform installation and
with non-hazardous voltages, there are situations where hazardous conditions may be service procedures.
present. Keithley Instruments products are designed for use with electrical signals that are rated
This product is intended for use by qualified personnel who recognize shock hazards Measurement Category I and Measurement Category II, as described in the International
and are familiar with the safety precautions required to avoid possible injury. Read and Electrotechnical Commission (IEC) Standard IEC 60664. Most measurement, control, and
follow all installation, operation, and maintenance information carefully before using the data I/O signals are Measurement Category I and must not be directly connected to mains
product. Refer to the user documentation for complete product specifications. voltage or to voltage sources with high transient over-voltages. Measurement Category II
If the product is used in a manner not specified, the protection provided by the product connections require protection for high transient overvoltages often associated with local
warranty may be impaired. AC mains connections. Assume all measurement, control, and data I/O connections are
for connection to Category I sources unless otherwise marked or described in the user
The types of product users are: documentation.
Responsible body is the individual or group responsible for use and maintenance of Exercise extreme caution when a shock hazard is present. Lethal voltage may be present
equipment, for ensuring that the equipment is operated within its specifications and on cable connector jacks or test fixtures. The American National Standards Institute
operating limits, and for ensuring that operators are adequately trained. (ANSI) states that a shock hazard exists when voltage levels greater than 30V RMS,
Operators use the product for its intended function. They must be trained in electrical 42.4V peak, or 60VDC are present. A good safety practice is to expect that hazardous
safety procedures and proper use of the instrument. They must be protected from voltage is present in any unknown circuit before measuring.
electric shock and contact with hazardous live circuits. Operators of this product must be protected from electric shock at all times. The
Maintenance personnel perform routine procedures on the product to keep it responsible body must ensure that operators are prevented access and/or insulated from
operating properly, for example, setting the line voltage or replacing consumable every connection point. In some cases, connections must be exposed to potential
materials. Maintenance procedures are described in the user documentation. The human contact. Product operators in these circumstances must be trained to protect
procedures explicitly state if the operator may perform them. Otherwise, they should be themselves from the risk of electric shock. If the circuit is capable of operating at or
performed only by service personnel. above 1000V, no conductive part of the circuit may be exposed.
Do not connect switching cards directly to unlimited power circuits. They are intended When fuses are used in a product, replace with the same type and rating for continued
to be used with impedance-limited sources. NEVER connect switching cards directly to protection against fire hazard.
AC mains. When connecting sources to switching cards, install protective devices to Chassis connections must only be used as shield connections for measuring circuits,
limit fault current and voltage to the card. NOT as safety earth ground connections.
Before operating an instrument, ensure that the line cord is connected to a properly- If you are using a test fixture, keep the lid closed while power is applied to the device
grounded power receptacle. Inspect the connecting cables, test leads, and jumpers for under test. Safe operation requires the use of a lid interlock.
possible wear, cracks, or breaks before each use.
If a screw is present, connect it to safety earth ground using the wire
When installing equipment where access to the main power cord is restricted, such as recommended in the user documentation.
rack mounting, a separate main input power disconnect device must be provided in This symbol on an instrument means caution, risk of danger. The user should refer
close proximity to the equipment and within easy reach of the operator. to the operating instructions located in the user documentation in all cases where
For maximum safety, do not touch the product, test cables, or any other instruments the symbol is marked on the instrument.
while power is applied to the circuit under test. ALWAYS remove power from the This symbol on an instrument means caution, risk of danger. Use standard safety
entire test system and discharge any capacitors before: connecting or disconnecting
precautions to avoid personal contact with these voltages.
cables or jumpers, installing or removing switching cards, or making internal changes,
such as installing or removing jumpers. This symbol on an instrument shows that the surface may be hot. Avoid personal
contact to prevent burns.
Do not touch any object that could provide a current path to the common side of the
This symbol indicates a connection terminal to the equipment frame.
circuit under test or power line (earth) ground. Always make measurements with dry
hands while standing on a dry, insulated surface capable of withstanding the voltage
being measured. If the mercury symbol is on a product, it indicates that mercury is present in the
display lamp. Please note that the lamp must be properly disposed of according to
The instrument and accessories must be used in accordance with its specifications and federal, state, and local laws.
operating instructions, or the safety of the equipment may be impaired.
WARNING This heading in the user documentation explains dangers that might result
Do not exceed the maximum signal levels of the instruments and accessories, as defined in personal injury or death. Always read the associated information very
in the specifications and operating information, and as shown on the instrument or test carefully before performing the indicated procedure.
fixture panels, or switching card.
FAQs
Safety Introduction Unpack Connect Test Next steps
CAUTION This heading in the user documentation explains hazards that could
damage the instrument. Such damage may invalidate the warranty.
Instrumentation and accessories shall not be connected to humans.
Before performing any maintenance, disconnect the line cord and all test cables.
To maintain protection from electric shock and fire, replacement components in mains
circuits - including the power transformer, test leads, and input jacks - must be
purchased from Keithley Instruments. Standard fuses with applicable national safety
approvals may be used if the rating and type are the same. Other components that are
not safety-related may be purchased from other suppliers as long as they are equivalent
to the original component (note that selected parts should be purchased only through
Keithley Instruments to maintain accuracy and functionality of the product). If you are
unsure about the applicability of a replacement component, call a Keithley Instruments
office for information.
To clean an instrument, use a damp cloth or mild, water-based cleaner. Clean the
exterior of the instrument only. Do not apply cleaner directly to the instrument or allow
liquids to enter or spill on the instrument. Products that consist of a circuit board with
no case or chassis (e.g., a data acquisition board for installation into a computer) should
never require cleaning if handled according to instructions. If the board becomes
contaminated and operation is affected, the board should be returned to the factory for
proper cleaning/servicing.
Introduction to the Model 707B or 708B Semiconductor Switching Matrix
The Models 707B and 708B provide outstanding low-current matrix
capability and let you control up to 576 matrix crosspoints in real
CD-ROM contents
time. Their large matrix format makes them well suited for your large
ATE system applications, such as semiconductor device The CD-ROMs that are included with your instrument contain:
characterization, wafer level reliability, parallel test, and modeling. The Test Script Builder Software and Models 707B and 708B
TSB add-in, which is a software tool you can use to create,
The Models 707B and 708B documentation includes: modify, debug, and store TSP test scripts
Quick Start Guide: Shows you how to unpack and set up the Switching product information
instrument to determine that the instrument is functional. Product documentation, including PDFs of the Quick Start
User's Manual: Provides an instrument overview and Guide, User's Manual, Reference Manual, the product data sheet,
example-based training to familiarize you with the instrument. product specifications, and rack-mount kit instructions
Reference Manual: Provides comprehensive information about Product documentation for compatible switch cards
the instrument, including descriptions of all features and IVI Instrument Driver, driver for National Instrument's
programming commands. LabVIEW◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
