                                                                         Model 8010-DTB-220
Keithley Instruments, Inc.
28775 Aurora Road
                                                                                 Device Test Board
Cleveland, Ohio 44139
1-888-KEITHLEY
http://www.keithley.com



Description
   The 8010-DTB-220 is a device test board for testing 3-terminal devices in a TO-220 or TO-247 package and
   2-terminal axial-lead devices. This test board is used with Keithley Instrument Models 8010 High Power Device
   Test Fixture and 8011 High Current Test Socket Kit.
                                          Figure 1: Model 8010-DTB-220




Electrical characteristics
   The following characteristics apply when used with the Model 8010 High Power Device Test Fixture:
