Image preview - the first page of the document
>> Download JL-558 documenatation <<Text preview - extract from the document 3-WAY 3-SPEAKER SYSTEM
JL-558
SERVICE MANUAL
2000-4/B51-5614-00 (Z/Z)
EXTERNAL VIEW
Tweeter
(193143)
Tapping screw
(231405)
Mid-range
(311505)
Grille holder
Grille assy
(230003)
(266581)
Tapping screw
(234987)
Grille assy Woofer
(311506) Network unit
(266582)
(266577)
Note: Please contact to KENWOOD SERVICE Note: Please contact to KENWOOD ELECTRONICS CANADA
CORPORATION California 90810, U.S.A. INC. Ontario, Canada L5T 1S8
If any question on service parts. If any question on service parts.
SPECIFICATIONS
Enclosure........................................................................Bass-reflex type (magnetically shielded)
Woofer...........................................................................................................250 mm, cone type
Mid range ......................................................................................................100 mm, cone type
Tweeter ..........................................................................................................13 mm, dome type
Impedance ................................................................................................................................8
Maximum input level...........................................................................................................100 W
Dimensions ...................................................................................................W: 203mm (8")
H: 900mm (35-5/16")
D: 327mm (12-7/8")
Net Weight ................................................................................................13.4kg (29.5 lb / piece)
Note:
KENWOOD follows a policy of continuous advancements in development.
For this reason specifications may be changed without notice.
JL-558
NETWORK /PARTS LIST
DIVIDING NETWORK UNIT
C1 R1
BLU
+
1.8
