Image preview - the first page of the document
>> Download JL-998 documenatation <<
Text preview - extract from the document
3-WAY 3-SPEAKER SYSTEM
JL-998
SERVICE MANUAL
2000-4/B51-5615-00 (Z/Z)
EXTERNAL VIEW
Tweeter
(193143)
Tapping screw
(231405)
Mid -range
(193034)
Grille holder
(230003)
Tapping screw
(234971)
Woofer
(193131)
Grille assy Network unit
(266564) (232809)
Note: Please contact to KENWOOD SERVICE Note: Please contact to KENWOOD ELECTRONICS CANADA
CORPORATION California 90810, U.S.A. INC. Ontario, Canada L5T 1S8
If any question on service parts. If any question on service parts.
SPECIFICATIONS
Enclosure........................................................................Bass-reflex type (magnetically shielded)
Woofer...........................................................................................................380 mm, cone type
Mid-range ......................................................................................................100 mm, cone type
Tweeter ..........................................................................................................13 mm, dome type
Impedance ................................................................................................................................8
Maximum input level...........................................................................................................100 W
Dimensions ...................................................................................................W: 470mm (18-1/2")
H: 900mm (35-7/16")
D: 279mm (11")
Net Weight ..............................................................................................12.5kg (27.6 lb / piece)
Note:
KENWOOD follows a policy of continuous advancements in development.
For this reason specifications may be changed without notice.
JL-998
DIVIDING NETWORK UNIT / PARTS LIST
DIVIDING NETWORK UNIT
C1
W1 ; BLU
+ +
