Image preview - the first page of the document
>> Download KDC-203S & 209S documenatation <<
Text preview - extract from the document
CD RECEIVER
KDC-203S/209S
SERVICE MANUAL
C 2001-3 PRINTED IN JAPAN
B51-7780-00 (4) 0
VISTEON GENUINE
KDC-203S KDC-209S
KDC-203S 40Wx4 KDC-209S 40Wx4
AUD CRSC AUD CRSC
COMPACT COMPACT
DIGITAL AUDIO AUTO DIGITAL AUDIO AUTO
LOUD SCAN RDM REP PWR OFF AME ADJ
LOUD SCAN RDM REP PWR OFF AME ADJ
Refer to KDC-316S's information of the service manual "KDC-316S/316V/37MR"
(B51-7700-00) for KDC-203S/209S's information except the following parts.
PARTS LIST
New Parts
Parts without Part No. are not supplied.
A N Desti- A N Desti-
Ref. No. d e Parts No. Description Ref. No. d e Parts No. Description
d w nation d w nation
KDC-203S/209S KDC-203S/209S do not include the following parts.
704 3C A64-2439-01 PANEL (704 but a service part) PA1 3C PANEL ASSY
AC1 2D CORD WITH PINPLUG
207 3C B10-4094-01 FRONT GLASS K2 - INSULATING COVER
207 3C B10-4095-01 FRONT GLASS K3 SWITCH UNIT (X13- or X16-)
SWITCH UNIT (X13- or X16-) C8 ,9 CHIP C
301 2C B11-1327-04 OPTICAL DIFFUSER K2 R20 CHIP R
301 2C B11-1333-14 OPTICAL DIFFUSER K3 D18 ,19 LED
ELECTRIC UNIT (X25-)
PL1 ,2 B30-1485-05 LAMP K2 CN2 PIN ASSY
PL1 ,2 B30-1543-05 LAMP K2 J4 CYLINDRICAL RECEPTACLE
PL1 ,2 B30-1513-05 LAMP K3 J5 PIN JACK
C221-224 ELECTRO
ED1 B38-1061-05 LIQUID CRYSTAL K2 C225,226 CHIP C
ED1 B38-1062-05 LIQUID CRYSTAL K3 C401,402 ELECTRO
C403 ELECTRO
C5 CK73EB1C225K CHIP C 2.2UF K K2 C404 CHIP C
R137 CHIP R
R12 RK73FB2A102J CHIP R 1.0K J 1/10W K2 R170 RD
R13 RK73FB2A470J CHIP R 47 J 1/10W K2 R171 RD
R221-224 RD
IC2 RS-171 ANALOGUE IC K2 R225-228 RD
ELECTRIC UNIT (X25-) R229-232 RD
R138 RK73GB1J473J CHIP R 47K J 1/16W R401,402 RD
R403 RD
IC4 TDA7384A ANALOGUE IC R404 RD
R405-409 RD
R410,411 RD
R412-414 CHIP R
D401,402 ZENER DIODE
D403,404 ZENER DIODE
D409-411 ZENER DIODE
Q40 DIGITAL TRANSISTOR
Q221-224 DIGITAL TRANSISTOR
K2 : KDC-209S
K3 : KDC-203S
