Image preview - the first page of the document
>> Download KRC-788 & HN4 documenatation <<
Text preview - extract from the document
CASSETTE RECEIVER
KRC-788/HN4
SERVICE MANUAL
C 2001-1 PRINTED IN JAPAN
B51-7743-00 (4) 0
NISSAN GENUINE
Destination Thailand
KRC-788 System E's +
PWR
OFF
DISC PROG
DAB
45W X 4
EJECT
B NR SCAN B.S/RDM REP D.SCN MTL/M.RDM MENU
AUTO DISP
LOUD AME NAME.S
NF
AUD
DISC
Refer to the service manual "KRC-788" (B51-7596-00) for KRC-788/HN4's information
except the following parts.
New Parts
PARTS LIST
Parts without Part No. are not supplied.
A N
Ref. No. d e Parts No. Description
d w
KRC-788/HN4 does not include the following parts.
- INST. MANUAL (ENGLISH,CHINESE)
- WARRANTY CARD
- ID CARD
- ITEM CARTON CASE
DC1 1C DC CORD ASSY
212,213 1C ESCUTCHEON
222 1C LEVER
258 1C MOUNTING HARDWARE ASSY
262 1C STAY
274,275 1C SCREW SET
