Image preview - the first page of the document
>> Download KRC-288 & AD3 documenatation <<
Text preview - extract from the document
CASSETTE RECEIVER
KRC-288/AD3
SERVICE MANUAL
C 2000-8 PRINTED IN JAPAN
B51-7665-00 (4) 36
DAIHATSU GENUINE
Destination Australia
PWR
SRC OFF
REW FF
PR OG
CLK
AUTO AME ADJ CD/MD-CHANGER CONTROL CRSC
KRC-288
DISC
FM
LOUD SCAN RDM REP T.C/D.SCN M.RDM
ATT 1 2 3 4 5 6 AUD AM
A.ADJ
Refer to KRC-288's information of the service manual "KRC-208S/218_KRC-268/288_...."
(B51-7586-00) for KRC-288/AD3's information except the following parts.
PARTS LIST
New Parts
Parts without Part No. are not supplied.
A N Des-
Ref. No. d e Parts No. Description tina-
d w tion
KRC-288/AD3
204 1F A22-2848-03 SUB PANEL ASSY
208 1F A53-1685-03 CASSETTE LID
DC1 E30-4872-05 DC CORD
KRC-288/AD3 does not include the following part.
- INSTRUCTION MANUAL
indicates safety critical components.
