>> Download LS-N773 documenatation <<Text preview - extract from the document BOOK-SHELF TYPE 3-WAY 5-SPEAKER SYSTEM
LS-N773
SERVICE MANUAL
(XD-V737/V737S) 2000-6/B51-5641-00 (Z/K)387
EXTERNAL VIEW
Dressing panel
assy
(A21-3317-08):(L) Binding head
Tweeter
(A21-3318-08):(R) tapping screw
(T03-0794-05)x2
(N44-4010-45)x4
Cap
(F09-1502-08)
Tweeter Push terminal
(T03-0793-05) (E21-0910-08)
Grille holder
(J19-3976-08)X4
Binding head
tapping screw
(N44-4025-45)x4
Woofer
(T10-0955-05)x2
Binding head
tapping screw
(N44-4010-45)x4 Push terminal
(E21-0282-08)
Grille ass'y
(B06-1445-08)
SYSTEM MAIN UNIT SPEAKER
XD-V737 RXD-V737 LS-N773
XD-V737S RXD-V737S LS-N773
SPECIFICATIONS
Enclosure ..............................................................................................................Bass-reflex type
Woofer .....................................................................................................130 mm, cone type x2
Tweeter......................................................................................................65 mm, cone type x2
Tweeter ...........................................................................................................25 mm, piezo type
Impedance ................................................................................................................................6
Maximum input level .................................................................................................High 30 W
Low 100 W
Dimensions .................................................................................................W: 235mm (9-1/4")
H: 410mm (16-1/8")
D: 291.5mm (11-1/2")
Net Weight ................................................................................................6.6kg (14.55 lb / piece)
Note:
KENWOOD follows a policy of continuous advancements in development. For this
reason specifications may be changed without notice.
LS-N773
DIVIDING NETWORK UNIT/PARTS LIST
DIVIDING NETWORK UNIT BLU +
SP3
WHT -
RED +
SP2
-
B LK
C1
+
YEL +
2.2
