Image preview - the first page of the document



>> Download W-38 documenatation <<

Text preview - extract from the document

INSTALLATION
                       AND

             OPERATING
                             MANUAL




DELUXE STEREOPHONIC

        AMPLIFIER                     MODEL   W-38
AM- AM/ FM/ SW   Tuner- Combination




                          DISTRIBUTOR




                                                     www.hifiengine.com
                            I.     FEATURES OF THE W-38

1.   General Stereophonic Amplifier
It is a general purpose stereo amplifier capable of FM and shortwave
reception enabling you to enjoy all types of broadcasts and recordings.

2.   Sufficient Output
Output is 14 watts per channel, or 28 watts in total.    It is possible,
therefore, to reproduce richly the most powerful tones of an orchestra.

3.   Direct Current
Hum is entirely eliminated with a DC filament supply system adopted
to the equalizer circuit.

4.   Loudness Control
No matter how low you keep the volume, you can enjoy "on-the-spot"
listening by adjusting the Loudness Control.
5.   Rumble Filter
Irritating low level motor rumbling disturbances can be filtered out
with the Rumble Filter.

6.  RP-Cord Tape Recorder Terminal
The W-38 is equipped with a special socket of the kind agreed to among
the major tape recorder manufacturers (a RP-cord terminal by which
recording and reproduction are possible using only one connection) as
well as an ordinary terminal.   Accordingly, you can freely enjoy high
fidelity recording and reproduction with any kind of tape recorder.

7.   Magic Eye
You can select radio stations quickly and accurately with the magic eye.
