Image preview - the first page of the document
>> Download SW-36HT documenatation <<
Text preview - extract from the document
POWERED SUBWOOFER
SW-36HT/36HT-S/306
SERVICE MANUAL
2002-8 PRINTED IN KOREA
B51-5810-00 (K/K) 1714
Knob Push knob
(K29-0580-08)x2 (K27-0211-08)
Grille assy Power switch AC power cord
(B06-1616-08) (S66-0203-08) (E30-5493-18):KP
(E30-5998-08):E
SPECIFICATIONS
Type ...............................................Subwoofer system with built-in Speaker Units ................................200 mm (8") Cone type
amplifier Nominal Impedance ......................4
[Amplifier] Dimensions ...................................Width : 299 mm (11-3/4")
Rated Output Power .....................120 W RMS (100 Hz, 10, 4 )
Height : 333 mm (13-1/8")
Input Sensitivity & Input
Impedance 200 mV (12 k) Depth : 483 mm (19")
Rated Power Consumption ..........100 W Net Weight .....................................15 kg (33.1 lb)
[Speaker] Supplied accessories
Enclosure ......................................Bass-Reflex, Floor Standing Pin-plug cord .............................................................1
Type
Cushion .....................................................................4
NOTE: DO NOT REMOVE THE GRILLE.
Notes:
1. Kenwood follows a policy of continuous advancements in development. For this reason, specifications may be
changed without notice.
2. Full performance may not be exhibited in extremely cold locations (below 0 deg. C). 70%
SW-36HT/36HT-S/306
ADJUSTMENT
INPUT OUTPUT AMPLIFIER ALIGNMENT
No. ITEM ALIGN FOR FIG.
SETTINGS SETTINGS SETTINGS POINTS
Unless otherwise specified, the individual switches should be set as following :
POWER : ON NO SIGNAL INPUT
Connect a DC
