Image preview - the first page of the document
>> Download TK-7150_PL documenatation <<
Text preview - extract from the document
Dec-02
USA Corporation,
Communications Division
Land-Mobile Price List
TK-7150/8150
VHF / UHF Trunking & Conventional Mobile Radios
Model Description List
VHF Includes: KMC-27B Mic., KCT-23M DC Cable, Mounting bracket, key label inserts
TK-7150K 136-174 MHz, 50 W, 128 Conventional/ 32 LTR Zones max. $783.00
UHF Includes: KMC-27B Mic., KCT-23M DC Cable, Mounting bracket, key label inserts
TK-8150K 450-500 MHz, 45 W, 128 Conventional/ 32 LTR Zones max. $817.00
TK-7150/8150 FEATURES:
GENERAL FEATURES: gnition Sense On/Off
50W VHF & 45W UHF Timed Power Off with Ignition Sense
DSP Processing Inhibit PTT ID in TA
Wide Frequency Range PTT Release Tone
Wide/Narrow Channel Spacing Minimum Volume
Programmable Power Per Channel Control Tones/Offset Volume
Remote Mount Capable (KRK-9) Power On Text
3.5 W Front Panel Speaker Embedded Message (64 Char.)
12 W External Speaker Output Embedded Message w/Password
Companded Audio Per Channel Data Password ("Anti-piracy")
12-Character Alphanumeric Display Radio Password (Radio Lock)
3-Digit Numeric Sub-Display Clone Capability (enable/disable)
Dot Matrix Backlit LCD PC Programming & Tuning
TX/Busy LED Indicators Flash ROM Firmware LTR Talk Around
LCD Backlight Control Windows Programming Software Scan Revert Group Display
6 PF Keys with Label Inserts KES-5 External Speaker (New) System Scan & Group Scan
Volume Knob / Power ON/Off Button MIL-Spec/Noise-Cancel Mic Options Auto System Search
Zone/ CH Selector Knob KDS-100 Compatible (KCT-40) FLEETSYNC / FLEETSYNC II ***
Dynamic Channel/Zone Allocation KGP-2A/2B Compatible (KCT-40) PTT ID (Digital ANI)
Home CH/GID MIL-STD 810 C, D, E & F - Caller ID Display (per CH;, 100 ID List)
5 CH. Direct Channel Select (User) --------------------------------------------------- Status Messaging (50 Msg. List capacity)
CH/GID Selector Tracking & Recall INCLUDED ITEMS - 70 Custom Dispatch Messages
Send GPS KMC-27B Standard Microphone - 9 Reserved Special Use Messages
Speaker Internal-External Switch DC Cable ST# 98 - Man Down Emergergency (portables)
Squelch Level Mounting Bracket ST# 99- Emergency Status
FleetSync & FleetSync II *** Instruction Manual ST# 88- Emergency Mode Off
Encryption/Scrambler Board Support 2 Year Warranty Card ST# 89- Horn Alert Request
ANI Board Support CONVENTIONAL ZONE OPERATION ST# 90- Stun radio (No TX)
Dual ANI & Scrambler Board Install 128 Zones (max.) ST# 91- Stun radio (No TX / No RX audio)
Emergency Call (DTMF& FleetSync) Dual Priority Scan ST# 92- Turn off Stun
DTMF Decode Selective Call Single/Multi-Zone & List Scan ST# 93- ACK stun is ON
DTMF Deadbeat Disable Scan Revert Channel Display ST# 94- ACK stun is OFF
DTMF PTT ID & DTMF Emergency ID Scan Delete/Add ST# 80-87, 95-97 (reserved for future use)
Auto-Dial Memory (32 numbers) Nuisance Delete Selective Call (100 ID List, Last 3 Message Stack)
Horn Alert (Programmable Output) QT/DQT Encode & Decode Short Text Messages** (stored/display)
Public Address Operator Selectable Tone (16 OST) Long Text Message** (req. KDS-100, KCT-40//36)
DB-25 Accessory Connector 2-Tone Decode (4 x 4 Decoding) PC Serial Control Interface** (req. computer serial cable)
AUX A Output (High or Open Coll.) - Tones: A, B, C, D; Seq.:A-B, A-C, C-B, A-D, C-D FS GPS Data** (req. aftermarket GPS/modification)
AUX B Output (High or Open Coll.) - 4 Decode Groups x 4 Decode pairs ** Fleetsync Enhanced features (factory enabled)
AUX Inputs 1-4 (F-Port) - 8 Unique Alert Tone Patterns *** FleetSync II air protocol is not compatible with the
AUX Outputs 1-4 (F-Port) 2-Tone Encode (32 Selectable Pairs) orginal FleetSync air protocol. The TK-7150/8150 FleetSync
16 CH. Remote Ctrl. I/O's (F-Port) BCL/BCL Override, TOT & TA PC Serial interface is the same regardless of FleetSync or
Data Port I/O's (F-Port) LTR ZONE OPERATION FleetSync II operation with dispatch software applications.
FleetSync COM 1 & 2 (DB-25) 32 Zones (max.)
6-Pin Accessory Connector 250 GIDs max.
1 P7150/8150
Dec-02
USA Corporation,
Communications Division
Accessories for the TK-7150/8150 Series Radios
Model Description List
MOBILE INSTALLATION ACCESSORIES
KCT-18 Ignition sense cable (plugs into TK-7150/8150 mobile 6-pin acc.conn.) $13.00
KCT-22M Remote Control Cable - 8 Feet; TK-7150/8150; 90-Series $70.00
KCT-22M2 Remote Control Cable - 17 Feet (typical sedan length); TK-7150/8150; 90-Series $80.00
KCT-22M3 Remote Control Cable - 25 Feet; TK-7150/8150; 90-Series $90.00
KCT-23M DC Cable (35-50W Dash mount; pos/neg. 10 ft. leads)- same as supplied with radio $30.00
KCT-23M3 DC Cable (35-50W Remote mount; pos.23 ft.; neg. 3.3. ft. leads) $33.00
KCT-36 KCT-34/35/40 Extension Cable; 117.6 inches (9.8 ft) $42.00
KCT-40 KGP-2A/2B & KDS-100 Radio Interface Cable for 50-Series Mobiles $28.00
KLF-2 Line Filter (suppresses alternator whine, 25dB, 25A max). $39.50
KRK-9 Remote Control Kit for TK-7150/8150 (purchase KCT-22M/M2/M3 cable separately) $47.00
CONTROL STATION INSTALLATION ACCESSSORIES
Notes: FleetSync PC Serial Interface connections to a computer can be made with a standard computer serial
cable; DB-25 male (mobile) -to- DB-9/25 female (computer). The TK-7150/8150 does not require a speciaL
Kenwood KCT-cable. KMB-xx Mounting Cases- there are no TK-7150/8150 compatible mounting cases
for the KPS-10A/AM or KPS-14/15 DC power
supplies (the KMB-2B & KMB-20 are not compatible).
KMC-9C Control Station Desktop Microphone (8-pin mod. plug) $82.00
KPS-10A Regulated DC power supply (gray color; 110VAC) $209.00
KPS-14 DC Switching Power Supply (117/230 VAC; 10A max. continuous, 14A peak) Compatible with $135.00
medium power compact mobiles only: 60/60G/62/62G/80/50-series mobiles
KPS-15 DC Switching Power Supply (117/230 VAC; 23A max. continuous, 25A peak) Compatible with $167.00
medium & high power compact mobiles only: 60/60G/60H/60HG/62/62G/60H/60HG/80/50-series mobiles
MICROPHONES AND SPEAKERS
KES-4 External speaker, 20W max input (plugs into TK-7150/8150 mobile 6-pin acc.conn.) $59.00
KES-5 External speaker, 20W max input (plugs into TK-7150/8150 mobile 6-pin acc.conn.) AVAIL. 1/2003 $59.00
KMC-27A MIL-SPEC & Noise Canceling dynamic mobile microphone (8-pin mod. plug) $99.00
KMC-27B Standard dynamic mobile microphone (8-pin mod. plug) --- same as supplied with radio $40.00
KMC-28A MIL-SPEC & Noise Canceling dynamic mobile microphone (8-pin mod. plug) w/ DTMF $155.00
KMC-9C Control Station Desktop Microphone (8-pin mod. plug) $82.00
SERVICE RELATED ACCESSORIES
KPG-46 Mobile Programming interface cable (8-pin mic jack mobiles) for 60G/62G/80/50-Series Mobiles N/A
KPG-79D P.C. Programming Software for TK-7150/8150 Windows 98,2000,Me & XP $99.00
Call Kenwood Parts at 800-367-7514 to order the following:
E30-3382-05 Clone cable $13.54
J29-0697-XX Mounting bracket for TK-7150/8150 (hardware N99-0395-x5)- same as supplied with radio TBD
KDS-100 FLEETSYNC MOBILE DATA TERMINAL (See KDS-100 price pages for details)
KDS-100 FleetSyncT M Data Terminal- Includes mounting bracket, mounting hardware and DC Cable $595.00
KCT-40 KGP-2A/2B & KDS-100 Radio Interface Cable for 50-Series Mobiles $28.00
KCT-36 KCT-34/35/40 Extension Cable; 117.6 inches (9.8 ft) $42.00
KPG-71D Programming Software for KDS-100 WindowsTM 95/98/Me $99.00
KGP-2A/2B AVL UNITS (See KGP-2A/2B AVL price pages for details)
KGP-2A GPS Receiver / Modem Unit (includes one dash-mount GPS antenna, mounting bracket, screw set $525.00
KGP-2B Base Modem Unit $225.00
KCT-40 KGP-2A/2B & KDS-100 Radio Interface Cable for 50-Series Mobiles $28.00
KCT-36 KCT-34/35/40 Extension Cable; 117.6 inches (9.8 ft) $42.00
KPG-73D Programming Software for KGP-2A/2B WindowsTM 95/98/Me $99.00
2 P7150/8150
Dec-02
USA Corporation,
Communications Division
Accessories for the TK-7150/8150 Series Radios
Model Description List
DIGITAL ANI
