>> Download TM-281A-MARS-CAP-Mod documenatation <<
Text preview - extract from the document
ASI-0104
Supplementary Info. Amateur Radio Division
Subject: TM-281A MARS/CAP Modification Date: September 7, 2011
This modification is provided "as is," and is subject to change without notice. Kenwood USA Corporation makes no warranty of
any kind with regard to this modification procedure, including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose. Kenwood USA Corporation shall not be liable for any error or for incidental or consequential
damage in connection with the furnishing, performance, or use of this modification procedure.
It is illegal to operate outside the limits of your class license or permits.
Procedure:
1. Turn off the transceiver and disconnect the antenna and DC supply.
2. Remove the screw on each side of the top panel.
3. Remove the top cover as shown below.
4. Locate and carefully remove Chip Resistor R768 on theTX/RX Board.
