Image preview - the first page of the document



>> Download KROHNHITE 3901 Operating documenatation <<

Text preview - extract from the document

Model 3901
GPIB Programmable Elliptical Filter
115dB/Octave Slope
1Hz to 99kHz
HP, LP, BP, BR

Operating Manual
Service and Warranty
 Krohn-Hite Instruments are designed and manufactured in accordance with
 sound engineering practices and should give long trouble-free service under
 normal operating conditions. If your instrument fails to provide satisfactory
 service and you are unable to locate the source of trouble, contact our Service
 Department at (508) 580-1660, giving all the information available
 concerning the failure.

 DO NOT return the instrument without our written or verbal authorization to
 do so. After contacting us, we will issue a Return Authorization Number which
 should be referenced on the packing slip and purchase order. In most cases, we
 will be able to supply you with the information necessary to repair the instru-
 ment, avoiding any transportation problems and costs. When it becomes nec-
 essary to return the instrument to the factory, kindly pack it carefully and ship
 it to us prepaid.

 All Krohn-Hite products are warranted against defective materials and work-
 manship. This warranty applies for a period of one year from the date of deliv-
 ery to the Original Purchaser. Any instrument that is found within the one year
 warranty period not to meet these standards, will be repaired or replaced. This
 warranty does not apply to electron tubes, fuses or batteries. No other war-
 ranty is expressed or implied.

 Krohn-Hite Corporation reserves the right to make design changes at any time
 without incurring any obligation to incorporate these changes in instruments
 previously purchased.

 Modifications to this instrument must not be made without the written consent
 of an authorized employee of Krohn-Hite Corporation.
                   Model 3901

                         1Hz to 99kHz
                     Low-Pass, High-Pass
                    Band-Pass, Band-Reject
               GPIB Programmable Elliptical Filter




               Serial No. _____________________




                  Operating Manual



     15 Jonathan Drive, Unit 4, Brockton, MA 02301-5566 U.S.A.
              Tel: (508) 580-1660; Fax: (508) 583-8989
             www.krohn-hite.com; [email protected]


                 Copyright 2005 Krohn-Hite Corporation
All rights reserved. Contents of this publication may not be reproduced in
   any form without the written permission of Krohn-Hite Corporation.
                             Printed in U.S.A.
                              Ver. 05.16.05
Notes
                                                                                     Table of Contents




                              Table of Contents
1.0   Section 1
      1.1 Introduction
