Image preview - the first page of the document
>> Download MB394 documenatation <<
Text preview - extract from the document
MICROWAVE OVEN
SERVICE MANUAL
MODEL : MB-394A, MH-594A
CAUTION
BEFORE SERVICING THE UNIT, READ THE
SAFETY PRECAUTIONS IN THIS MANUAL.
SPECIFICATIONS
ITEM DESCRIPTION
MODEL MB-394A MH-594A
Power Requirement 230 Volts AC 50 Hz
Single phase, 3 wire grounded
Microwave 1,200W 1,200W
Grill 1,100W 1,100W
Combination 2,250W 1,200W
Power Output 800 Watts full microwave power (IEC705)
Microwave Frequency 2,450 MHz
Magnetron 2M214 - 39F
Timer 90 min.
Outside Dimensions 483 (W) x 285 (H) x 360 (D) mm
Cavity Dimensions 312 (W) x 198 (H) x 316 (D) mm
Net Weight 13.7 kg (approx.)
Shipping weight 15.1 kg (approx.)
Control Complement Microwave Power for Variable Cooking
Power level
MAX .................................................. Full power throughout the cooking time
MED.-HIGH ........................................ approx. 80% of Full power
MEDIUM ............................................ approx. 60% of Full power
DEFROST .......................................... approx. 40% of Full power
LOW/WARM ...................................... approx. 20% of Full power
Grill, COMBI
Name Plate Location
Back side
Accessories Owner's manual
Glass tray
Rotating ring
Grill rack
This microwave oven is designed for household use only.
It is not recommended for commercial purposes.
1-1
OPERATING INSTRUCTIONS
FEATURES
Oven Front Plate
Window Door Screen
Door Seal
Display Window
Control Panel
Safety Door Lock System
Grill Rack Glass Tray
Rotating Ring
CONTROL PANEL
1. INDICATORS
2. SET CLOCK: Used to set the time of day.
3. MICRO: Used to select the desired power level
1 9 for microwave cooking.
4. GRILL: Used to select the grill cooking.
5. AUTO DEFROST: Used to select the auto weight
2 10
defrost.
3 11 6. AUTO COOK: Used to cook the foods listed by one
4
touch.
12
7. TIME: To set cooking times.
5 8. STOP/CLEAR: Used to stop oven and clear all
entries except time of day.
- CHILD LOCK
6
9. DISPLAY WINDOW
10. KITCHEN TIMER
11. COMBI: Used to select the combination cooking.
7
12. MORE/LESS: Used to change cooking time.
8 13 13. START: One tap allows oven to begin functioning.
4-1
OPERATING SEQUENCE
The following is a description of component functions 6. GRILL COOKING
during oven operation.
Desired
1. SETTING THE CLOCK Stop Grill cooking Time Start
Set Set the Touch
Stop clock correct hour start 7. COMBINATION COOKING
Desired Desired
Set the Touch Stop combi Start
cooking Time
correct minute start category
8. AUTO WEIGHT DEFROST
NOTE: You can set 12 hour clock or 24 hour clock
optionally.
Desired Desired
Stop defrost cooking Start
2. CANCEL FUNCTION category Weight
Touch the STOP pad whenever you need to
cancel an entry or a function currently in use. 9. CHILD LOCK
The display will either return to the last item entered This oven has a CHILD LOCK feature
