Image preview - the first page of the document
>> Download 868EXPLOD documenatation <<
Text preview - extract from the document
EXPLODED VIEW/PARTS LIST
q
CABINET
26 22
21
23 28
25 20
26
q : Refer to the SPPL (Service Parts Price List). before order the part.
31
REF.NO. PART NO. DESCRIPTION
18 1 3790RCP006A WINDOW CST-R
2 3790RCP005B WINDOW CST-L
3 3580RCA003A DOOR CST-R
11
17 19
4 3580RCA002A DOOR CST-L
5 422-085E SPRING DOOR
16 13 29 6 4940SC0053B KNOB JOG
7 3680SC0004A LENS JOG
27 8 4940SC0055B KNOB VOLUME
9 4940RCV002A KNOB ROTARY
10 3720RCF002A PANEL FRONT(WITHOUT MIC JACK)
15 10 3720RCF002B PANEL FRONT(WITH MIC JACK)
11 353-025TAAA SCREW (3 10.5)
30 12 4901SK0001C DAMPER ASSY
13 384-535A GRIDE EJECT ASSY
12 14 3680RCA001A LENS FUNC
7 14
15 3550RC0002D COVER FRONT
6 16 3790RCP002B WINDOW AMP
17 3790RCP003B WINDOW CD
8 13 18 4940RCT004A KNOB DIMMER
19 4940RCT003A KNOB MAIN
20 3580RCC001A DOOR CD
12 21 4405SCE002A CD MECHA.(CDM-H1303)
4 34
5 9 22 246-444K DECO PLATE
23 3090S-0003F CABINET TOP
3 11 24 6730S-G004A DECK MECHA.(AUTO STOP)
10 24 24 6730S-G004B DECK MECHA.(AUTO REVERSE)
25 3720S-0036D PANEL SIDE
25 26 353-025C SCREW(3 10)
27 3140S-P907A CHASSIS MAIN
5 28 3720RCZ002A PANEL BACK
26 29 1TRL0402418 SCREW
2 30 3806RC0001A DECO COVER
31 4920S-E007A HEAT SINK MAIN
1 33 32 32 3300SCM003A PLATE SHIELD-DECK
26 33 353-022K SCREW(2 3)
34 4940RCV003A KNOB MIC(OPTIONAL)
33
- 39 -
q
TAPE DECK MECHANISM: AUTO STOP DECK(OPTIONAL)
Serviceable Parts List
LOCA.NO. PART NO. DESCRIPTION LOCA.NO. PART NO. DESCRIPTION
1 6768S-AP02A 50-268-3016 ARM PIGEON TRIGGER 9 6768S-HP03B TC231F HEAD PIGEON E HEAD
2 6768S-AP02B 50-239-4026 ARM PIGEON CS 10 6768S-GP02A 50-093-4069 GEAR PIGEON CLUTCH
3 6768S-AP02C 50-239-4027 ARM PIGEON SW 11 6768S-MP02A 50-219-4028 MOLD PIGEON SW BOX
4 6768S-BP04A 02-083-4165 BELT/FELT PIGEON B 12 6768S-SP02A 01-082-4646 SPRING PIGEON LEAF
5 6768S-BP04B 02-083-4166 BELT/FELT PIGEON A 13 6768S-TP01B MSW17220MVQ0 SWITCH PIGEON MOD
6 6768S-BP04C 02-084-4161 BELT/FELT PIGEON B 14 6768S-VP01A 50-093-4125 SOLENOID PIGEON
7 6768S-BP04D 02-084-4163 BELT/FELT PIGEON A 15 6768S-XP01B SG211V SPECIAL PIGEON PHOTO IN
8 6768S-HP03A TC881CB067B HEAD PIGEON PB HEA 16 6768S-OP01A 50-093-4198 MOTOR ASSY PIGEON
- 41 -
q
TAPE DECK MECHANISM: AUTO REVERSE DECK(OPTIONAL)
Serviceable Parts List
LOCA.NO. PART NO. DESCRIPTION LOCA.NO. PART NO. DESCRIPTION
1 6768S-AP02A 50-268-3016 ARM PIGEON TRIGGER 9 6768S-GP02A 50-093-4069 GEAR PIGEON CLUTCH
2 6768S-AP02B 50-239-4026 ARM PIGEON CS 10 6768S-MP02A 50-219-4028 MOLD PIGEON SW BOX
3 6768S-AP02C 50-239-4027 ARM PIGEON SW 11 6768S-SP02A 01-082-4646 SPRING PIGEON LEAF
4 6768S-BP04A 02-083-4165 BELT/FELT PIGEON B 12 6768S-TP01B MSW17220MVQ0 SWITCH PIGEON MOD
5 6768S-BP04B 02-083-4166 BELT/FELT PIGEON A 13 6768S-VP01A 50-093-4125 SOLENOID PIGEON
6 6768S-BP04C 02-084-4161 BELT/FELT PIGEON B 14 6768S-XP01B SG211V SPECIAL PIGEON PHOTO IN
7 6768S-BP04D 02-084-4163 BELT/FELT PIGEON A 15 6768S-OP01A 50-093-4198 MOTOR ASSY PIGEON
8 6768S-HP03A TC881CB067B HEAD PIGEON PB HEA 16 6768S-EP01A 50-093-4070 HEAD ASSY PIGEON
- 41 -
q
CD MECHANISM
734 REF.NO. PART NO. DESCRIPTION
700 4405SCE002A CD MECHANISM ASS'Y(CDM-H1303)
701 4860SB0002A CLAMP ASS'Y
729 702 4405SCB001A MECHANISM ASS'Y(KSM-213CCM)
707 3040SB0003A BASE PU(CDM-H1303)
708 4900SB0001A DAMPER RUBBER
709 709 88H-0002 SCREW(3X9X12)
709 710 6756SBX001A SCREW(2.6X10X10)
736 711 4680SBP001A MOTOR PULLEY ASS'Y
712 3040SB0002A BASE MAIN
732 713 4974SB0001A GUIDE CAM
733 714 4970SBN002A SPRING CAM
728 715 4400SB0001A BELT MAIN
716 4471SB0001A GEAR CAM ASS'Y
717 4470SB0005A GEAR MAIN
718 4470SB0003A GEAR PULLEY
719 4470SB0004A GEAR LOADING
720 4470SB0007A GEAR PU UP-A
721 4470SB0008A GEAR PU UP-B
727 731
722 4470SB0006A GEAR PU DOWN
735 723 88H-0003 SCREW(3X12X10)
730
718 724 6871SD21RAD PCB ASS'Y CAM
723 725 6871SB21RAD PCB ASS'Y CLOSE
725 726 6871SC21RAD PCB ASS'Y OPEN
719 701 727 4371SB0002A SHAFT ASS'Y TRAY
716
728 3390SB0001A TRAY LOADING
722 729 3390SBO002A TRAY DISC
730 4974SB0003A GUIDE WORM
731 4400SB0001B BELT TRAY
721
732 4470SB0010A GEAR TRAY A
733 4470SB0011A GEAR TRAY B
712 734 88H-0004 SCREW(3X12X12)
734
735 6871SF21RAD PCB ASS'Y SENSOR
720 713 714 736 4680SBP002A MOTOR ASS'Y TRAY
717
726 724
702
715 710 710
711 708
708
709
707
- 42 -
q
OPTICAL PICK-UP CARRIAGE
1
3
4
2
Serviceable Parts List
REF.NO. PART NO DESCRIPTION
4405SCB001A MECHANISM ASSEMBLTY, KSM-213CCM
1 6756S-G001A GEAR
2 6756S-T001A SWITCH
3 6756S-X001A PICK-UP, KSS-213C
4 6756S-O001A MOTOR
- 43 -
