SECTION 4. SPEAKER SECTION
MODEL: FE-976E
850
865
854
852
851
861
861
854
853
855
858
856
856
857
862
864
859
860
863
(Region Code) MODEL: FE-976E
A : LGEMS , B: LGEPS , C: LGEPR , D : LGEDG , E : LGECB RUN DATE :03.MAY,2001
F : LGEMK , G : LGEIS , H : LGEPL NSP : NON SVC PART
LOCA. NO. PART NO. A B C D E F G H DESCRIPTION SPECIFICATION REMARKS
850 3701RM0008A O O O O O O O O NET ASSY ASSY FE-976E STANDARD NET META NSP
851 3720RMF001A O O O O O O O O PANEL FRONT(FE-868E) NSP
852 6400RMEA01A O O O O O O O O SPEAKER,TWEETER 05N45EHC1019 FE-976E EAW 6OHM
853 6400RMEE02A O O O O O O O O SPEAKER,GENERAL 10K60EHC1017 FE-976E EAW 6OHM
854 353M050C O O O O O O O O SCREW BH 3.5X16 FBK
855 6400RMEJ01A O O O O O O O O SPEAKER,GENERAL 16R90EHC1018 FE-976E EAW 6OHM
856 353M050D O O O O O O O O SCREW WOOD DRC 3.5X 12 BK
857 4350RM0001A O O O O O O O O RING WOOFER(FE-868E) NSP
858 3110RM0001A O O O O O O O O CASE TOP(FE-969E/868E) NSP
859 3091RMW016A O O O O O O O CABINET ASSY FE-976E PILOT PB 12T NSP
859 3091RMW016B O CABINET ASSY FE-976E LGEDG 12T E-1 NSP
860 6871RU2012C O O O O O O O O PWB(PCB) ASSY,SUBSET(AUDIO) (FE-969VE)SPK CORD AY,YEL+BK, NSP
861 353M025G O O O O O O O O SCREW TAPTITE, 3X10 FZMY"
862 353M025K O O O O O O O O SCREW TAPTITE, 3X12 FZMY"
863 6871RU2012B O O O O O O O O PWB(PCB) ASSY,SUBSET(AUDIO) (FE-969E)SUPER WF SPK CORD AY, NSP
864 4766SMN024B O O O O O O O O FELT DUCT(FE-868E/969E) BLACK NSP
865 3530RMM001D O O O O O O O O GRILLE METAL(FE-976E) NOT BADGE HOLE NSP
