Image preview - the first page of the document



>> Download FFH-1920_1950_2-1 documenatation <<

Text preview - extract from the document

SECTION 2. ELECTRICAL
                                            ADJUSTMENTS
This set has been aligned at the factory and normally will not require further adjustment. As a result, it is not
recommended that any attempt is made to modificate any circuit. If any parts are replaced or if anyone tampers
with the adjustment, realignment may be necessary.

IMPORTANT
1. Check Power-source voltage.
2. Set the function switch to band being aligned.
3. Turn volume control to minimum unless otherwise noted.
4. Connect low side of signal source and output indicator to chassis ground unless otherwise specified.
5. Keep the signal input as low as possible to avoid AGC and AC action.

TAPE DECK ADJUSTMENT
1. AZIMUTH ADJUSTMENT

       Deck Mode                    Test Tape                    Test Point                 Adjustment           Adjust for
                                                                                            DECK Screw
         Palyback                   MTT-114                     Speaker Out                                       Maximum
                                                                                           Azimuth Screw

                                                                         Electronic             Dual-trace
                                                                         Voltmeter              synchroscope

                         Head
                                       Playback Mode
                                                           Speaker Out
                                                  L out
                             L ch                                                               CH1 CH2

                 Test Tape                 Unit
                 MTT-114     R ch                                                                     GND


                                                  R out



                                    Figure 1. Azimuth Adjustment Connection Diagram

2. TUNER ADJUSTMENT
    (FM)

              Item                         Test Point                                 Adjustment               Adjust for
           DC Voltage                 Check Point TP1, TP2                              L101                   0V
