Image preview - the first page of the document
GENERAL&SPEC


>> Download GENERAL&SPEC documenatation <<

Text preview - extract from the document
SECTION 1. GENERAL
                         SERVICING PRECAUTIONS
NOTES REGARDING HANDLING OF THE PICK-UP
1. Notes for transport and storage
  1) The pick-up should always be left in its conductive bag until immediately prior to use.
  2) The pick-up should never be subjected to external pressure or impact.


                    Storage in conductive bag                                    Drop impact




2. Repair notes
  1) The pick-up incorporates a strong magnet, and so should never be brought close to magnetic materials.
  2) The pick-up should always be handled correctly and carefully, taking care to avoid external pressure and
     impact. If it is subjected to strong pressure or impact, the result may be an operational malfunction and/or
     damage to the printed-circuit board.
  3) Each and every pick-up is already individually adjusted to a high degree of precision, and for that reason
     the adjustment point and installation screws should absolutely never be touched.
  4) Laser beams may damage the eyes!
     Absolutely never permit laser beams to enter the eyes!
     Also NEVER switch ON the power to the laser output part (lens, etc.) of the pick-up if it is damaged.


                                                            NEVER look directly at the laser beam, and don't let
                                                            contact fingers or other exposed skin.



  5) Cleaning the lens surface
     If there is dust on the lens surface, the dust should be cleaned away by using an air bush (such as used
     for camera lens). The lens is held by a delicate spring. When cleaning the lens surface, therefore, a
     cotton swab should be used, taking care not to distort this.
                                                                             Pressure
                      Magnet
                                                                                               Pressure


                                 How to hold the pick-up

                                                           Cotton swab



                                                Conductive Sheet
  6) Never attempt to disassemble the pick-up.
     Spring by excess pressure. If the lens is extremely dirty, apply isopropyl alcohol to the cotton swab. (Do
     not use any other liquid cleaners, because they will damage the lens.) Take care not to use too much of
     this alcohol on the swab, and do not allow the alcohol to get inside the pick-up.

                                                      - 1-2 -
NOTES REGARDING COMPACT DISC PLAYER REPAIRS
1. Preparations
  1) Compact disc players incorporate a great many ICs as well as the pick-up (laser diode). These
     components are sensitive to, and easily affected by, static electricity. If such static electricity is high
     voltage, components can be damaged, and for that reason components should be handled with care.
  2) The pick-up is composed of many optical components and other high-precision components. Care must
     be taken, therefore, to avoid repair or storage where the temperature of humidity is high, where strong
     magnetism is present, or where there is excessive dust.

2. Notes for repair
  1) Before replacing a component part, first disconnect the power supply lead wire from the unit
  2) All equipment, measuring instruments and tools must be grounded.
  3) The workbench should be covered with a conductive sheet and grounded.
     When removing the laser pick-up from its conductive bag, do not place the pick-up on the bag. (This is
     because there is the possibility of damage by static electricity.)
  4) To prevent AC leakage, the metal part of the soldering iron should be grounded.
  5) Workers should be grounded by an armband (1M)
  6) Care should be taken not to permit the laser pick-up to come in contact with clothing, in order to prevent
     static electricity changes in the clothing to escape from the armband.
  7) The laser beam from the pick-up should NEVER be directly facing the eyes or bare skin.



                                                                  Armband




                                                                         Resistor
                                                                         (1 Mohm)
                                           Resistor
                                                         Conductive
                                           (1 Mohm)
                                                         Sheet




                                                      - 1-3 -
                                  ESD PRECAUTIONS
Electrostatically Sensitive Devices (ESD)
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components
commonly are called Electrostatically Sensitive Devices (ESD). Examples of typical ESD devices are integrated
circuits and some field-effect transistors and semiconductor chip components. The following techniques should
be used to help reduce the incidence of component damage caused by static electricity.
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off
    any electrostatic charge on your body by touching a known earth ground. Alternatively, obtain and wear a
    commercially available discharging wrist strap device, which should be removed for potential shock reasons
    prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ESD devices, place the assembly on a conductive
   surface such as aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ESD devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static" can
   generate electrical charges sufficient to damage ESD devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ESD
   devices.
6. Do not remove a replacement ESD device from its protective package until immediately before you are ready
   to install it. (Most replacement ESD devices are packaged with leads electrically shorted together by
   conductive foam, aluminum foil or comparable conductive materials).
7. Immediately before removing the protective material from the leads of a replacement ESD device, touch the
   protective material to the chassis or circuit assembly into which the device will by installed.

  CAUTION : BE SURE NO POWER IS APPLIED TO THE CHASSIS OR CIRCUIT, AND OBSERVE ALL OTHER
            SAFETY PRECAUTIONS.


8. Minimize bodily motions when handing unpackaged replacement ESD devices. (Otherwise harmless motion
   such as the brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can
   generate static electricity sufficient to damage an ESD device).



 CAUTION. GRAPHIC SYMBOLS

               THE LIGHTNING FLASH WITH APROWHEAD SYMBOL. WITHIN AN EQUILATERAL
               TRIANGLE, IS INTENDED TO ALERT THE SERVICE PERSONNEL TO THE PRESENCE
               OF UNINSULATED "DANGEROUS VOLTAGE" THAT MAY BE OF SUFFICIENT MAGNITUDE
               TO CONSTITUTE A RISK OF ELECTRIC SHOCK.

               THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO ALERT
               THE SERVICE PERSONNEL TO THE PRESENCE OF IMPORTANT SAFETY INFORMATION
               IN SERVICE LITERATURE.




                                                     - 1-4 -
                                   SPECIFICATIONS

         General   Power supply                             Refer to the back panel of the unit.
                   Power consumption                                       40W
                   Mass                                                   3.4kg
                   Extemal dimensions(W X H X D)                330 X 77 X 210mm
         CD        Frequency response                                   40 -18,000Hz
                   Signal-to-noise ratio                                  70dB
                   Dynamic range                                           70dB
                   Tuning Range                                      87.5-108.0MHz
                   Intermediate Frequency                                10.7 MHz
         FM
                   Signal-to-noise ratio                                61/58dB
 TUNER




                   Frequency Response                                   60-10,000Hz
                   Tuning Range                                      522 - 1,611kHz
         AM(MW)    Intermediate Frequency                                 450kHz
                   Signal-to-noise ratio                                  35/31dB
                   Frequency Response                                 100-2,000 Hz
         AMP       Output Power                                            20W + 20W
                   T.H.D                                                   0.15%
                   Frequency Response                                  42-25,000Hz
                   Signal-to-noise ratio                                  80dB
         Speaker   MODEL                           FE-S198E/FE-S197E                FE-S198AWE
                   Type                            Base Reflex 2 way 2 Speaker      Active Subwoofer/Bass
                                                   System                           Reflex 1 Way 1 Speaker
                                                                                    System
                   Impedance                       6                                4
                   Frequency Response              100-20,000Hz                     45-250Hz
                   Sound Pressure Level            83dB/W(1m)                       84dB/W(1m)
                   Rated Input Power               20W                              50W
                   Max.Input Power                 40W                              100W
                   Net Dimension(W X H X D)        126 X 311 X 142.5mm              230 X 311 X 267mm
                   Net Weight                      1.0kg                            6.20kg

*Designs and speciflcations are subject to change without notice.




                                                    - 1-5 -
