Image preview - the first page of the document
>> Download FL-R88~5 documenatation <<
Text preview - extract from the document
EXPLODED VIEW/PARTS LIST[FL-R888K (P/N : 3828SAD010A)]
CABINET
REF.NO. PART.NO. DESCRIPTION Q'TY
A 3141S-P003A CHASSIS ASSEMBLY, MAIN 1
A-1 213-302A CABINET, TOP 1
A-2 265-023A FOOT ASSEMBLY 2
A-2-1 264-020A LEG, DECORATION 1
A-2-2 472-200G FELT 1
A-3 265-023B FOOT ASSEMBLY 2
A-3-1 264-020B LEG, FOOT 1
A-3-2 472-200G FELT 1
A-4 3141SUP002A CHASSIS ASSEMBLY 1
A-4-1 322-304A SUPPORTER, MECHA-L 2
A-4-2 322-304B SUPPORTER, MECHA-R 2
A-4-3 4974S-0062A GUIDE, MD 1
A-4-4 384-145A GUIDE, PWB 1
A-4-5 3140S-P001A CHASSIS, MAIN 1
A-4-6 1TRL0302416 SCREW, 3.0 x 8.0 6
A-5 353-025C SCREW, TAPTITE 3 x 10 14
B 3721S-M011A PANEL ASSEMBLY, FRONT 1
B-1 4940S-1145A KNOB, SELECT 1
B-2 4940S-1149A KNOB, OPEN 1
B-3 4940S-1150A KNOB, VOLUME 4
B-4 4940S-1151A KNOB, MIC VOLUME 2
B-5 3790S-0145A WINDOW, FRONT 1
B-6 3858S-X012A SHHEET, FRONT 1
B-7 3580S-0145A DOOR, MD 1
B-8 241-015A MARK, GOLDSTAR 1
B-9 4810S-0145A BRACKET, FRONT 1
B-10 353-025C SCREW, TAPTITE 3 x 10 25
B-11 3721SUM002A PANEL ASSEMBLY, FRONT 1
B-11-1 221-146A COVER, KNOB 1
B-11-2 3720S-0145A PANEL, FRONT 1
B-11-3 4940SU1147A KNOB, CONTROL 1
B-11-4 353-025C SCREW, TAPTITE 3 x 10 1
B-12 4941SU1119A KNOB, ASSEMBLY, ARRAY 1
B-12-1 4940S-1146S KNOB, ARRAY 1
B-12-2 3680S-0145A LENS, KNOB-1 1
B-12-3 3680S-0145B LENS, KNOB-2 1
B-12-4 3680S-0145C LENS, KNOB-3 1
B-12-5 3858S-0145A SHEET, LED 1
C 3721S-P002A PANEL ASSEMBLY, BACK 1
C-1 3720S-0146A PANEL, BACK 1
C-2 1TRL0402416 SCREW, 4.0 8.0 4
C-3 353-025C SCREW, TAPTITE 3 x 10 18
D 4405S-E001A MECHANISM ASSEMBLY 1
48
EXPLODED VIEW/PARTS LIST[FL-R888K (P/N : 3828SAD010A)]
CABINET
