Image preview - the first page of the document
>> Download A30008~2 documenatation <<
Text preview - extract from the document
Operation
s Name and Function-Remote Control
Remote Control
Signal transmitter
1
2
Heat pump model 3
Cooling model
4 8
5 9
6 10
7
11
OPERATION DISPLAY CHAOS SWING BUTTON
1 Displays the operation conditions. 7 Used to stop or start louver movement and set the
desired up/down airflow direction.
START/STOP BUTTON
2 Operation starts when this button is pressed and SLEEP MODE AUTO BUTTON
stops when the button is pressed again. 8 Used to set Sleep Mode Auto operation.
OPERATION MODE SELECTION BUTTON AIR CIRCULATION BUTTON
3 Used to select the operation mode. 9 Used to circulate the room air without cooling or
heating (turns indoor fan on/off).
ON/OFF TIMER BUTTONS
4 Used to set the time of starting and stopping ROOM TEMPERATURE CHECKING
operation. 10 BUTTON
Used to check the room temperature.
5 TIME SETTING BUTTONS
Used to adjust the time. RESET BUTTON
11 Used prior to resetting time or after replacing
TIMER SET/CANCEL BUTTONS batteries.
6 Used to set the timer when the desired time is
obtained and to cancel the Timer operation.
-36-
