Image preview - the first page of the document
>> Download TCC-67~6 documenatation <<
Text preview - extract from the document
EXPLODED VIEW
1.REMOTE CONTROLLER SECTION (2) Individual Parts
Ref. No. Part No. Description
3720S-0671A TCC-670, 2 COLOR
3720S-0671C TCC-670, 1 COLOR
FRONT
1 3720S-0671D DH6000, 1 COLOR
PANEL
3720S-0671G TCC-570, 2 COLOR
3720S-0671H BECO:CR-1280, 1 COLOR
4940S-0693A KNOB TCC-670, DH6000
2
4940S-0693C SKIP TCC-570, CR-1280
3 4940S-0692A KNOB AS/PS
4 4940S-0689A KNOB FF
5 442-690A SPRING
6 4940S-0690A KNOB REW
7 4940S-0691A KNOB FUNCTION BD/LD
8 442-690A SPRING
9 4940S-0688A KNOB EJECT
4940S-0684A KNOB PRESET TCC-670, DH6000
10
4940S-0684C #3, 6 TCC-570, CR-1280
4940S-0683A KNOB PRESET TCC-670, DH6000
11
4940S-0683C #2, 5 TCC-570, CR-1280
4940S-0682A KNOB PRESET TCC-670, DH6000
12
4940S-0682C #1, 4 TCC-570, CR-1280
4940S-0681A TCC-670, DH6000
13 KNOB POWER
4940S-0681C TCC-570, CR-1280
14 4940S-0687A KNOB RELEASE
15 442-690B SPRING
16 4940S-0686A KNOB LEVER
17 4940S-0685A KNOB MODE
18 447-674A CUSHION-L
19 464-672A REFLECTOR SUB-R/R
20 353-028A SCREW 2 x 6
21 3110S-0673A CASE HOUSING
(1) Assembly Parts 22 659-148E DISPLAY KXN19552AAN
Ref. No. Part No. Description 23 563-013G RUBBER CONNECTOR
6710S-670AA TCC-670, 2 COLOR-AMBER/GREEN 24 231-836S LCD SHEET
6710S-670BA REMOCON TCC-670, 1 COLOR-GREEN 25 464-670A REPLECTOR LCD-R
A 6710S-670CA ASS'Y DH6000, 1 COLOR-AMBER 26 447-673A CUSHION MAIN-L
6710S-570AA (1~31) TCC-570, 2 COLOR-AMBER/GREEN 27 464-671A REPLECTOR MAIN-R/L
6710S-570BA BECO:CR-1280, 1 COLOR-GREEN 28 353-028A SCREW 2 x 6
6871SA26YAA FRONT 2 COLOR-AMBER/GREEN 29 3720S-0672A REAR PANEL
B 6871SA26YAC PCB 1 COLOR-GREEN 30 353-645A SCREW 2 x 8
6871SA26YAD ASS'Y 1 COLOR-AMBER 31 353-645A SCREW 2 x 8
1
2. MAIN SECTION
Ref. No. Part No. Description
4 442-566B SPRING UNIT-PUSH
5 423-561B SHAFT UNIT-PUSH
6 353-028A SCREW 2 x 6
7 4810S-0674A BRACKET HOLDER GUIDE-B
8 442-691A SPRING HOLDER GUIDE-S
9 324-675A HOLDER GUIDE-H
10 442-567A SPRING POWER
11 353-028A SCREW 2 x 6
12 333-562A LEVER UNIT PUSH
13 1MBC0261416 SCREW 2.6 x 4
14 221-340F COVER BOTTOM
15 231-973A SHEET INSULATION
16 353-022B SCREW 2.6 x 6
17 353-052P SCREW 2.6 x 6
18 353-022B SCREW 2.6 x 6
19 3141S-0670A CHASSIS MAIN COMMON
20 353-022B SCREW 2.6 x 6
21 563-957B POWER CONNECTOR (12PIN)
22 4810S-0330A BRACKET IC HOLD
23 3141S-0074A CHASSIS SIDE ASS'Y
24 255-326A HEAT SINK
25 1MRC0262418 SCREW 2.6 x 8
26 1MRC0302818 SCREW 3 x 12
27 353-022B SCREW 2.6 x 6
28 353-052P SCREW 2.6 x 6
29 217-124A DIN SLEEVE CASE
30 353-022B SCREW 2.6 x 6
(1) Assembly Parts
31 221-339F TOP COVER
Ref. No. Part No. Description 6871SA26ZAC TCC-670, FOR LGEPS
3720S-0670A TRIM TCC-670 6871SA26ZAD DH6000, FOR PROFILE
3720S-0670D DH6000
(2) Individual Parts MAIN PCB
PANEL 32 6871SA26ZAE TCC-670, FOR MANDARIN/BROTHERS
A ASS'Y
3720S-0670Y ASS'Y CR-1280 Ref. No. Part No. Description 6871SA26ZAF TCC-570, FOR BROTHERS
3720S-0670Z (1~12) TCC-570 1 3720S-0670A TRIM PANEL 6871SA26ZAG CR-1280, FOR BECO
6871S-26ZAC TCC-670, FOR LGEPS 2 442-330B SPRING DOOR 6871SB26ZAC TCC-670, FOR LGEPS
MAIN+RF 6871SB26ZAD DH6000, FOR PROFILE
6871S-26ZAD DH6000, FOR PROFILE 226-668A TCC-670
PCB RF PCB
B 6871S-26ZAE TCC-670, FOR MANDARIN/BORTHERS 226-668D DOOR DH6000 6871SB26ZAE TCC-670, FOR MANDARIN/BROTHERS
ASS'Y 3 33
226-668F CST TCC-570 6871SB26ZAF ASS'Y TCC-570, FOR BROTHERS
6871S-26ZAF TCC-570, FOR BROTHERS
(32+33)
6871S-26ZAG CR-1280, FOR GECO 226-668G CR-1280 6871S26ZAG CR-1280, FOR BECO
2
3.DECK SECTION
B
(1) Assembly Parts
Ref. No. Part No. PART NAME Ref. No. Part No. PART NAME
A 410-670A DECK ASS'Y (3+10+11+12) B 419-020P DECK TN-717MH-231
2 99T-0848 MOTOR ASS'Y
3 99T-0849 MAIN GEAR
(2) Individual Parts 8 99T-0850 P.R ARM ASS'Y-F
Ref. No. Part No. PART NAME 14 99T-0851 CENTER PULLEY B
1 1MPC0301418 SCREW 3 x 4 25 99T-0852 P.R ARM ASS'Y-R
2 3140S-0673A CHASSIS FRONT-C 33 99T-0853 HEAD P5044SD-99H
3 324-674A HOLDER FF/REW-H 37 99T-0854 FLYWHEEL CAP ASS'Y
4 1MPC0301418 SCREW 3 x 4 38 99T-0855 MODE SW MIS-AC-3-2S
5 4810S-0673A BRACKET DECK-B 39 99T-0856 MAIN BELT
6 1MPC0301418 SCREW 3 x 4 41 99T-0868 MUTE SW MSW-1547N
7 4810S-0675A BRACKET PCB 60 99T-0857 TURN OVER GEAR
8 353-022B SCREW 2.6 x 6 67 99T-0858 TURN OVER GEAR COLARR
9 1MPC0301418 SCREW 3 x 4 69 99T-0859 CENTER GEAR
10 419-020P DECK TN-717MH-231 92 99T-0860 F.R LEVER SPRING
11 353-022B SCREW 2.6 x 6 96 99T-0862 TURN OVER SPRING
12 324-673A HILDER EJECT-H 97 99T-0863 PACK SLIDER
105 99T-0864 SKELTON SW SKD-12AR
210 99T-0865 WASHER 1.2 x 3.0 x 0.25
211 99T-0866 WASHER 2.1 x 5.0 x 0.13
216 99T-0867 WASHER 0.85 x 2.8 x 0.2
