Image preview - the first page of the document
>> Download exploded view parts list documenatation <<
Text preview - extract from the document
EXPLODED VIEW & PARTS LIST
s MAIN SECTION
405
205
203
810
101
405
LOCA. NO. PART NO. DESCRIPTION SPECIFICATION
105 101 3034R-0008A REFLECTOR LEFT(TCC-6020)
107 850 400 102 3034R-0009A REFLECTOR RIGHT(TCC-6020)
202
400 104 3110R-0195A CASE FRONT(TCC-6020)
112 113 405 105 4850R-0025A CUSHION SPONGE-L(TCC-6020)
106 4850R-0025B CUSHION SPONGE-R(TCC-6020)
600 401
107 5020R-0353A BUTTON VOLUME(TCC-6020)
108 102
111 206
108 5020R-0354A BUTTON TUNE UP/DN(TCC-6020)
109 5020R-0355A BUTTON BTN PRESET1,2(TCC-6020)
106 401
400 110 5020R-0356A BUTTON BTN PRESET3,4(TCC-6020)
109
111 5020R-0357A BUTTON BUTTON AS/PS(TCC-6020)
209 112 5020R-0365A BUTTON BUTTON MD/LD(TCC-6020)
207 113 5020R-0405A BUTTON EJECT(TCC-8020)
401
150 3721RFZ004B PANEL ASSY TRIM TCC-8020
201 401 151 3580R-A001A DOOR CST (AUDIO) TCC-8020
800
110 208
401 152 3720R-M001B PANEL,AUDIO TRIM(TCC-8010)
104 153 423-561F SHAFT UNIT PUSH.FX-2000
210
154 442-333AAAA SPRING COIL TCC-5610
155 442-565A SPRING L-LEVER TCH-71
400 156 442-566E SPRING COIL TCC-5610
157 4510S-0016A LEVER UNIT PUSH FX-2000
403 158 4510S-0025A LEVER LOCK TCC-5610
151 159 4810S-1018A BRACKET LEVER,LOCK TCC-5610
200 3110S-P035A CASE TERMINAL TCC-5610
860 211 201 4810R-0080A BRACKET DECK-FRONT(TCC-8010 LOGIC)
154 200 202 4810R-0081A BRACKET DECK-REAR(TCC-8010 LOGIC)
404
400 203 3110R-0197B CASE REAR(TCC-8010/8020)
204 3140S-P017A CHASSIS MAIN(TCC-5610)
205 3550S-0006A COVER TOP(TCC-5610)
402 159 150 206 3110S-P026A CASE DIN SLEEVE (TCC-670/570/680 AL)
801 207 442-976E SPRING COIL TCC-5610
158
208 5020S-0001A BUTTON RELEASE(TCC-5610)
402
209 3790R-P014A WINDOW DISPLAY (TCC-8020)
155 210 3858R-X011A SHEET (MECH) EPE 80 40 0.5 WINDOW
152
211 4850RE0001A CUSHION RUBBER(5*5*30)
157 400 1MBC0262018 SCREW MACHINE,BINDING HEAD D 2.6 L 6.0 MSWR3/FZY
156 204 401 1MPC0301418 PAN HEAD MACHINE SCREW + D 3.0 L 4.0 MSWR3/FZY
402 1MBC0261416 BINDING HEAD MACHINE SCREW + + D2.6 L4.0 MSWR3/FZB
153
403 1MRC0302818 ROUND HEAD MACHINE SCREW + D 3.0 L 12 MSWR3/FZY
404 353-645A SCREW SPECIAL TAPPING 2X8 BK
405 353-028AAAA SCREW TAPTITE 2X6 FZMY
600 6730R-N001A DECK MECHANISM,AUDIO TN-708-143 TANASHIN CAR LOGIC
800 6871RE2021A PWB(PCB) ASSY,OEM(AUDIO) CTCC8010/8020 UKL01 BWT MAIN A
801 4920S-D001D HEAT SINK AL DC 170X40 TCC-5611
810 6871RE3020A PWB(PCB) ASSY,OEM(AUDIO) CTCC8020 UKL01 FRONT BWT
850 6871RE2125A PWB(PCB) ASSY,OEM(AUDIO) CTCC8010/8020 UKL01 BWT DECK A
860 6871RE2052B PWB(PCB) ASSY,OEM(AUDIO) CTCC8010 UKL01 MW RF ASS Y
- 23 -
s DECK MECHANISM SECTION
Serviceable Parts List
REF.NO. PART NO DESCRIPTION SPECIFICATION REF.NO. PART NO DESCRIPTION SPECIFICATION
600 6730R-N001A DECK MECHANISM,AUDIO TN-708-143 TANASHIN CAR LOGIC 608 6768R-RT01A DECK MECHANISM PARTS 1970-07-303 TANASHIN ROLLER (F)
601 6768R-BT01A DECK MECHANISM PARTS 1970-11-06 TANASHIN BELT/FELT 609 6768R-RT01B DECK MECHANISM PARTS 1970-07-304 TANASHIN ROLLER (R)
602 6768R-CT01A DECK MECHANISM PARTS 9C04-20-253 TANASHIN SCREW CAM 610 6768R-ST01A DECK MECHANISM PARTS 1970-04-12 TANASHIN SPRING E-L
603 6768R-CT01B DECK MECHANISM PARTS 9P02-20-031 TANASHIN SCREW TAM 611 6768R-ST01B DECK MECHANISM PARTS 1970-12-05 TANASHIN SPRING P.S
604 6768R-CT01C DECK MECHANISM PARTS 9C04-20-303 TANASHIN SCREW ADJ 612 6768R-ST01C DECK MECHANISM PARTS 1970-08-12 TANASHIN SPRING REE
605 6768R-HT01A DECK MECHANISM PARTS 6201-07-57 TANASHIN HEAD 613 6768R-WT01A DECK MECHANISM PARTS 9W02-50-040 TANASHIN WASHER 1.
606 6768R-QT01A DECK MECHANISM PARTS 1970-09-301 TANASHIN MOTOR SUB 614 6768R-WT01B DECK MECHANISM PARTS 9W01-20-050 TANASHIN WASHER 2.
607 6768R-QT01B DECK MECHANISM PARTS 1970-10-301 TANASHIN MOTOR MAI 615 6768R-XT01A DECK MECHANISM PARTS 1970-13-301 TANASHIN SPECIAL R
- 24 -
