Image preview - the first page of the document



>> Download LG_Version7_KIT_Ysus_Zsus documenatation <<

Text preview - extract from the document

Great Company Great People




                                     SVC Application Guide
                             PDP TV-H2 series, fitted with 42V7 Module




                                                Contents

                                        1       Outline & Guide

                                        2       Replacement List

                                        3       ROM Download
                                       * Attachment
                                         #1 Construction / Layout of V7 Plasma Module
                                         #2 Board Identification




          2006.08.21
 1. Outline & Guide

                                Issue                                        Field SVC Guide

                Applicable Models : All H2 series
                PDP-TV with 42V7 Module Fitted                       Market : Global (PAL BG/I/DK, SECAM L/L',
     General




                42PX1RV, 42PX2RV*,, 42PX3RV*,                         NTSC, PAL M/N)
                42PX4RV*, 42PX4MV*, 42PM3MV*
                * Others:##-42PX40 Series,                           When a PCB fitted to the PDP module fails
                  RZ-42PX30                                          (CTRL,YDRVTP,YDRVBT,XRLBT,XRRBT,YSUS,
                 Symptom                                               ZSUS) please only use the replacement part
                 : No Picture & Audio Sound OK                        number according to the list.

                                                                     Especially when Y-SUS Board fitted to the
