Image preview - the first page of the document
>> Download Disassembly(GR-432) documenatation <<Text preview - extract from the document3. DISASSEMBLY
3-1 DOOR 3-2 DOOR SWITCH
q Freezer Door 1. To remove the door switch, pull out it with a '--' type
1. Remove the hinge cover by pulling it upwards. driver as shown in (figure 9).
2. Loosen hexagonal bolts fixing the upper hinge to the 2. Disconnect the lead wire from the switch.
body and lift the freezer door.
HINGE COVER
BOLT DOOR SWITCH
HINGE
LEAD WIRE
Figure 9
Figure 6
3-3 THERMOSTAT
3. Pull out the door gasket to remove from the door foam 1. Remove the Cover Lamp-R by the use of '
