Image preview - the first page of the document
DISASS~1


>> Download DISASS~1 documenatation <<

Text preview - extract from the document
3. DISASSEMBLY
3-1 DOOR                                                          3-2 DOOR SWITCH
q Freezer Door                                                    1. To remove the door switch, pull out it with a '--' type
1. Remove the hinge cover by pulling it upwards.                     driver as shown in (figure 9).
2. Loosen hexagonal bolts fixing the upper hinge to the           2. Disconnect the lead wire from the switch.
   body and lift the freezer door.


                                          HINGE COVER

                                          BOLT
                                                                                                             DOOR SWITCH

                                          HINGE


                                                                                                                 LEAD WIRE

                                                                                                                   Figure 9

                                                 Figure 6
                                                                  3-3 THERMOSTAT
3. Pull out the door gasket to remove from the door foam          1. Remove the Cover Lamp-R by the use of '
