Image preview - the first page of the document
>> Download 077A_EV documenatation <<
Text preview - extract from the document
EXPLODED VIEW
943
913 400
150 153
510
170
P801
112
550
126
540
530
520
300
560
501
310 121
124
600
120
125
320
330 315
700
- 14 -
EXPLODED VIEW PARTS LIST The com onents identified by mark
critical for safety.
are
Replace only with part number specified.
Part No.
No. Description
25" 29"
112 6341V25004A 6341V29006A CPT ASSY
2426GE259AR - CPT SET,A59QDC259X 52M7ND N.ALLIED
120 120-D38C 120-D38C SPEAKER,8 OHM 15/25W
121 120-C76G 120-C76G SPEAKER,TWEETER C050TX-357K14 8 OHM
124 3550V00068A 3550V00068A COVER,DOME
125 4810V00165A 4810V00165A BRACKET,DOME(R)
126 4810V00165B 4810V00165B BRACKET,DOME(L)
150 150-201X 150-201Z COIL,DEGAUSSING
153 6150Z-1230F 6150Z-1240A DY
170 170-844G 170-844K CPT EARTH 29" 98T 4LUG
300 3091V00218P 3091V00217A CABINET ASSY
310 5020V00339A 5020V00339A BUTTON,CONTROL 4KEY
315 3580V00038A 3581V00024A DOOR ASSY,MAIN
320 320-062E 320-070G SPRING,COIL
330 5020V00337B 5020V00337B BUTTON,POWER
400 3809V00160B 3809V00169G BACK COVER ASSY
501 4810V00297A 4810V00233A BRACKET,MAIN
503 3500V00022A 3500V00022A BOARD,A/V(2 PHONE)
3500V00022C 3500V00022C BOARD,A/V(SCART)
510 6871VSM590B 6871VSM590A PWB ASSY,CPT FLAT
520 - 6871VMM618A PWB ASSY,MAIN CT29Q26PT,LGEGF
6871VMM635B 6871VMM618B PWB ASSY,MAIN CT25/29Q26ET
6871VMM618F 6871VMM618E PWB ASSY,MAIN CE25/29Q26ET
530 6871VSM588A 6871VSM588A PWB ASSY,VCD WITH PIP
6871VSM711A 6871VSM711A PWB ASSY,VCD W/O PIP,W/S-VHS
540 6871VSM589A 6871VSM589A PWB ASSY,ST RF
6871VSM589E 6871VSM589E PWB ASSY,ST RF
550 - 6871VSM605A PWB ASSY,HV 007A D-FOCUS
560 6871VSM607A 6871VSM607A PWB ASSY,CTL
600 - 6871VSM604B PWB ASSY,SIDE A/V(NOR. W/SVHS,
6871VSM604A 6871VSM604C PWB ASSY,SIDE A/V
700 0IGL120104A 0IGL120104A IC,CDS SENSOR MODULE(P1201-04)
913 332-229A 332-229M SCREW ASSY,HEXAGON HEAD
943 1PTF0403116 1PTF0403116 SCREW,TAP TITE D4.0 L16.0
P801 174-009V 174-009V CORD,POWER(W/HOLD,HOUSING)L=400,4.0
- 15 -
