EXPLODED VIEW : 21Q91/92
943
400
913
170 150
153
112
OPTION
501
520
530 174
124
123
300
120
121
540
310
320 700
330 600
- 22 -
The components identified by mark is
critical for safety.
EXPLODED VIEW PARTS LIST Replace only with part number specified.
LOCA. NO PART NO DESCRIPTIONS
112 6341V21009A CPT ASSY,A51QDX991X 21" S/S FLAT
120 120-D38C SPEAKER,MID-RANGE 8 OHM 15/25W 87
121 6400VG0002A SPEAKER,TWEETER T0520101 8 OHM 10
123 4810V00267A BRACKET,SPK
124 4810V00124A BRACKET,COVER
150 150-D02X COIL,DEGAUSSING CU 21" 60TURN 12 OHM
153 6150V-1019C DY,DIF-2192AA 21" SAMSUNG .
170 170-A01N CPT EARTH 21" 64T 2LUG 1P HSG
174 174-009E CORD,POWER(W/HOLD,HOUSING)
174-224G POWER,CORD
300 3091V00282C CABINET ASSY
310 5020V00431A BUTTON,CONTROL
320 320-062E SPRING,KNOB
330 5020V00430A BUTTON,POWER
400 3809V00208F BACK COVER ASSY(MC019A,PHONE) .
501 4810V00266A BRACKET,MAIN
520 6871VMM676R PWB ASSY,MAIN
6871VMM814C PWB ASSY,MAIN 21Q91KEX
6871VMM814H PWB ASSY,MAIN 21Q92KE
6871VMM745K PWB ASSY,MAIN 21Q92KEX
530 6871VSM962E PWB ASSY,(019A)21Q90 POWER
540 6871VSM962F PWB ASSY,(019A)21Q90 CONTROL KEY
600 6871VSM963J PWB ASSY,(019A)21Q91/92 SIDE A/V
700 0IGL120104A IC,CDS SENSOR MODULE(P1201-04)
913 332-057B SCREW ASSY,HEXAGON HEAD
943 1PTF0403116 SCREW,TAP TITE(P)[TRUSS HEAD] + D4.0 L16.0 MSWR3/FZB
- 23 -
