                                  EXPLODED VIEW


                    400




            590


                    203


                                                        520




                            300




                                                    610

      560                                                     540
                              600
                                            530                     201

580
              570
                                                                     120



                                                                          550




        200                                       204


                     PUSH
                                                                                210

                                                               202
                                      207
                      206

                                                  205

                                      - 28 -
                    EXPLODED VIEW PARTS LIST

No.      Part No.                                    Description

120   3141VSN196B        CHASSIS ASSEY,NP-00ED LP-XG22 SPK ASSY

200   3110V00074K        CASE BOTTOM ASSY,LP-XG22

      3110V00074P        CASE BOTTOM ASSY,LP-XG24

201   5900V08003D        FAN,DC G8015L12B2-RG 80MM 12

202   5900V06002D        FAN,DC G6015L12B-RH 60MM 12V

203   5900V02001B        FAN,DC F2510E12B 25MM 12V80M

204   4810V00146D        BRACKET ASSY,LAMP LP-XG22

205   3550V00089D        COVER,LAMP LUPOY (GP1006F) LP-XG22

      3550V00089E        COVER,LAMP LUPOY (GP1006F) LP-XG24

206   4778V00027E        LEG ASSY,FRONT LP-XG22

      4778V00027G        LEG ASSY,FRONT LP-XG24

207   4778V00027F        LEG ASSY,REAR LP-XG22

      4778V00027H        LEG ASSY,REAR LP-XG24

210   3501V00016D        BOARD ASSY,BALLAST & POWER LP-XG22

300   3680V00023B        LENS,RICOH LV091 0.9" LP-XG22

400   3110V00154B        CASE TOP ASSY,LP-XG22

      3110V00154D        CASE TOP ASSY,LP-XG24

520   6871VMN634A        PCB ASSY,MAIN NP00ED LP-XG22

530   6871VSN165A        PCB ASSY,SUB NP00ED LP-XG22 AV-IN

540   6871VSN167A        PCB ASSY,SUB NP00ED LP-XG22 PRE AMP

550   6871VPN028A        PCB ASSY,SMPS NP-00ED CAPACITOR-2 BOARD

560   6871VPN027A        PCB ASSY,SMPS NP-00ED LINE FILTER BOARD

570   6871VPN026A        PCB ASSY,SMPS NP-00ED CAPACITOR-1 BOARD

580   6871VPN025A        PCB ASSY,SMPS NP-00ED PFC BOARD

590   6871VSAA03A        PCB ASSY,KBD NP00EAD LP-XG22 LOCAL KEY

600   3141VPN012C        CHASSIS ASSY,SMPS NP-00ED AC IN &THERMO AS

610   3141VPN019A        CHASSIS ASSY,SMPS NP00EA PROTECT S/W ASSY F




                                  - 29 -
