Image preview - the first page of the document
>> Download 126CEV documenatation <<
Text preview - extract from the document
EXPLODED VIEW
943
913 400
170 150
153
112
530
540
520 174
501
124
123
120
300
121 310
550
600
320
330 700
- 18 -
The components identified by mark is
critical for safety.
EXPLODED VIEW PARTS LIST Replace only with part number specified.
LOCA. NO PART NO DESCRIPTIONS
112 6341V21009B CPT ASSY A51QDX992X DY SEOUNG CHANG
6341V21010A CPT ASSY 2426GDB30CA 21" FCD
6334V21004B CPT ASSY A51QAD992X 0G
2426GDB30CH CPT A51QDJ279X
2426GDB30CD CPT A51QDJ279X
120 120-D38C SPEAKER,MID-RANGE 8 OHM 15/25W 87 128*77
121 6400VG0002A SPEAKER,TWEETER T0520101(C76G) 8 OHM 10
123 4810V00267A BRACKET,SPK PP
4810V00267B BRACKET,SPK PP CKD
124 4810V00124A BRACKET,PP COVER
150 150-D02X COIL,DEGAUSSING CU 21" 60TURN 12 OHM
153 6150V-1014G DY QPC-E5409A 21" SENGCHANG S/S F
6150V-1019C DY DIF-2192AA(NF5)
6150Z-1223A DY DC21SPFL3 21" FCD
170 170-A01N CPT EARTH 21" 64T 2LUG 1P HSG
174 174-009Q POWER CORD(W/HOLD,HOUSING)L=300,4.0
6410VEH001G POWER CORD
300 3091V00439B CABINET ASSY LG FLAT
310 5020V00657A BUTTON,CONTROL
320 320-062E SPRING,KNOB
330 5020V00656A BUTTON,POWER
400 3809V00296A BACK COVER ASSEMBLY DVD
3809V00296C BACK COVER ASSEMBLY CKD DVD
3809V00296D BACK COVER ASSEMBLY 1SCART
3809V00296F BACK COVER ASSEMBLY 21FB20RQ W/LABEL
501 4810V00555A BRACKET, MAIN RT-21FB20(407AF)
4810V00555B BRACKET, MAIN RT-21FB20(60HR)
520 6871VMM886B PWB ASSY,MAIN 019A RT-21FB20VQ
6871VMM886C PWB ASSY,MAIN 019A RT-21FB20VE
6871VMM886E PWB ASSY,MAIN 019A RT-21FB20VQ SKD
6871VMM886J PWB ASSY,MAIN 019A RT-21FB20VE CKD
6871VMM792V PWB ASSY,MAIN 019A RT-21FB20VQ SCART
6871VMM792W PWB ASSY,MAIN 019A RT-21FB20RQ
6871VMM815C PWB ASSY,MAIN 019A RT-21FB20VE SKD
6871VMMA89P PWB ASSY,MAIN 019A RT-21FB20VE CKD
6871VMM767J PWB ASSY,MAIN 019A RF-21FB20RE CKD
540 6871VSM962W PWB ASSY,SUB (019A) FB20 POWER BOARD
6871VSMB16C PWB ASSY,SUB (019A) FB20 POWER BOARD
6871VSMB16F PWB ASSY,SUB (019A) FB20 POWER BOARD
6871VSMD38J PWB ASSY,SUB (019A) FB20 POWER BOAR
550 6871VSM962X PWB ASSY,SUB (019A) FB20 KEY CONTROL
6871VSMB16D PWB ASSY,SUB (019A) FB20 KEY CONTROL
6871VSMB16G PWB ASSY,SUB (019A) FB20 KEY CONTROL
6871VSMD38K PWB ASSY,SUB (019A) FB20 KEY CONTROL
600 6871VSM963T PWB ASSY,SUB (019A) FB20 SIDE-AV(HP&STE
6871VSMB15M PWB ASSY,SUB (019A) FB20 SIDE-AV(HP&S
6871VSMB16E PWB ASSY,SUB (019A) FB20 SIDE-AV
6871VSMB16H PWB ASSY,SUB (019A) FB20 SIDE-AV
700 0IGL120104A IC,CDS SENSOR MODULE(P1201-04)
913 332-057B SCREW ASSY,HEXAGON HEAD
943 1PTF0403116 SCREW,TAP TITE(P)D4.0 L16.0 MSWR3/FZB
- 19 -
