                   EXPLODED VIEW(CT-29K30E/ET/EX/EN)


                                                                            943




                                                                                        400




                  102
                         913
                                                   510
                               150
                                     153




                                           170

                  112
                                                               P801




                                                                            530


                                                                      540



                                                         331
                        120                  104


                                                                                  520



                                           300




            310




320
                                                   700

      330




                                                           - 1 -
                                                   The components identified by mark          is
                                                   critical for safety.
EXPLODED VIEW PARTS LIST                           Replace only with part number specified.




  LOCA. NO    PART NO             DESCRIPTIONS


    102      341-919C      HOLDER,D-COIL
    104      343-B52B      SUPPORTER
             6341V29002B   BARE CPT ASSY,PA2,D/TINT,SOUTH,NTSC
    112
             6341V29002A   BARE CPT ASSY,PA2,D/TINT,NORTH
             2426GF120CJ   CPT SET,A68QBC230X 01R7KT * S&E
             2426GF120CF   CPT SET,A68QBC230X 01M7KT * MEI-JDN
             2426GF120CH   CPT SET,A68QBC230X 00M7KD * LGEMT
    120      120-C77G      SPEAKER,GENERAL C122P02K1459 8OHM 10
             150-201T      COIL,DEGAUSSING *LGEAP
    150
             6140VC2001B   COIL,DEGAUSSING,CU 29" 60TURN 8.7OHM
    153      6150Z-1043M   DY,DC29SPPA2
    170      170-844D      CPT EARTH
    300      3091V00161A   CABINET ASSY
             3091V00161E   CABINET ASSY *RANKINE
    310      5020V00296A   BUTTON,CONTROL
    320      320-062H      SPRING,COIL
    330      5020V00297A   BUTTON,POWER
    331      6600VM2001A   SWITCH,PUSH POWER
    400      3809V00119A   BACK COVER ASSY
             3809V00119B   BACK COVER ASSY(LGEAP)
             3809V00119E   BACK COVER ASSY(RANKINE)
             6871VMM286E   PWB ASSY,MAIN 8CB 29K30ET *LGEAP
    520      6871VMM286F   PWB ASSY,MAIN 8CB 29K30E *LGEAP
             6871VMM286G   PWB ASSY,MAIN 8CB 29K30ET *ABANS,LGEIN
             6871VMM286L   PWB ASSY,MAIN 8CB 29K30EX *S&E
             6871VMM301F   PWB ASSY,MAIN 8CB 29K30EN *LGEMT
             6871VMM351B   PWB ASSY,MAIN 8CB 29K30ET *RANKINE
             6871VMM368B   PWB ASSY,MAIN 8CB 29K30ET *N.ALLIED,LGEGF
             6871VMM368C   PWB ASSY,MAIN 8CB 29K30E *BROTHERS
             6871VMM351H   PWB ASSY,MAIN 8CB 29K30 * LGEIN
             6871VSM341A   PWB ASSY,RF STEREO MC-8CB NICAM
    530
             6871VSM202A   PWB ASSY,AV STEREO
    540      6871VSM201A   PWB ASSY,TXT
             6871VSM201D   PWB ASSY,TXT(P/K)
    700      0IGL120104A   IC,CDS SENSOR MODULE(P1201-04)
    913      332-229A      SCREW ASSY,HEXAGON HEAD
    943      1PTF0403116   SCREW,TAP TITE D4.0 L16.0
             174-222Q      POWER CORD ASSY(SAA L=2200MM)*LGEAP
    P801
             174-009Q      CORD,POWER(W/HOLD,HOUSING)




                              - 2 -
