EXPLODED VIEWS
1. Cabinet and Main Frame Section
NOTE) Refer to "SECTION 5 REPLACEMENT
PARTS LIST" in order to look for the
part number of each part.
5 _ OPTIONAL PARTS
300
457
320
462
A46
1
SW70
457
323
LED502
4
1
MD30
275
3
330
462
250
452
A43
260
280
284
2
457
457
457
457
283
457
A00
457
1
A B C D
2-2
2.Packing Accessory Section
NOTE) Refer to "SECTION REPLACEMENT PARTS LIST
NOTE) in order to look for the part number of each part.
810 CABLE SET ASS'Y 801 INSTRUCTION ASS'Y
808 BATTERY
(Optional Parts)
803 PACKING ASS'Y
900 REMOCON
804 SHEET CUSHION
802 BOX CARTON
2-3
3.Remote Control Section
OPTIONAL PART
904
906
903
902
901
907
905
900
2-4
