BLOCK DIAGRAM (V-3310/D/T, V-3340/D/T)

             TS                    S/W
                              BR          BR
                      P.W.B
     BL
                   BL
                                                 BR
                                                 CORD
          MOTOR                                  REEL
                                                  ASM

                                    BL                   PLUG
                  BR:BROWN                     BL:BLUE


SCHEMATIC DIAGRAM (V-3310/D/T, V-3340/D/T)
             TS                    S/W
                              BR          BR
                      P.W.B
     BL
                                                 BR
      M                                        CORD
                                               REEL
                                                ASM

                                     BL                  PLUG

                  BR:BROWN                     BL:BLUE



CIRCUIT DIAGRAM (V-3310/D/T, V-3340/D/T)
           S/W        TS




                  C1
                  0.47
