Image preview - the first page of the document
>> Download LV 703 documenatation <<
Text preview - extract from the document
NICAM/Hi-Fi STEREO
Video Cassette Recorder
With VIDEO Plus+
OWNER'S MANUAL
MODEL: LV900/LV800/LV803/LV703
PAL
Before connecting, operating or adjusting this product,
please read this instruction booklet carefully and completely.
FOR THE GUARANTEE TERMS & CONDITIONS,
PLEASE REFER TO BACK COVER OF THIS
MANUAL.
Model No. CC999MI/CC989MI/CC939MI/CC936MI
Part No. 3834RP0067D
Precautions &
Plug wiring
Information
Position your VCR so that no bright light or This appliance is supplied with BS 1363 approved 13
sunlight falls directly onto it. Amp fused mains plug. When replacing the fuse
always use a 5 Amp BS 1362 approved type.
Care should be taken not to expose your
Never use this plug with the fuse cover omitted. To
VCR to any unnecessary vibration,
obtain a replacement fuse cover contact your
moisture, dust or heat.
supplying dealer or LG Electronics U.K. LTD.
If the mains sockets in your home differ, or are not
suitable for the type of plug supplied then the plug
During electrical storms it is advisable to unplug both
should be removed and a suitable type fitted.
the aerial cable and mains plug to prevent accidental
If the mains plug becomes severed from the mains
damage to your VCR and TV.
lead it must be destroyed. A mains plug with bared
Do not operate your VCR if it is damaged. wires is hazardous if engaged in a mains output line
Your VCR should not be repaired by anyone socket.
except qualified service personnel. If a 13 Amp BS 1363 plug is not suitable or any other
Never remove the top cover of your VCR as this can type of plug used, then this appliance must be
expose you to very high voltage and other protected by a 5 Amp fuse.
hazards. If your VCR does not operate properly, Should you need to change the plug
please check the Troubleshooting Check List on page The wires in this mains lead are coloured in accordance
34. If your VCR still does not operate properly, unplug with the following codes
it and call your dealer. BLUE ~ Neutral
BROWN ~ Live
GREEN & YELLOW ~ No connection to be made
Ensure that your VCR is placed in a position to As the colours of the wires in the mains lead of this
allow a free flow of air. appliance may not correspond with the coloured markings
identifying the terminals in your plug proceed as follows :
The wire which is coloured BLUE must be connected to the
The apparatus shall not be exposed to dripping
terminal which is marked with the letter N or coloured
or splashing and that no objects filled with liquids,
BLACK.
such as vases, shall be placed on the apparatus.
The wire which is coloured BROWN must be connected to
the terminal which is marked with the letter L or coloured
This product is manufactured to comply
with the radio interference requirements RED.
of EEC DIRECTIVE 89/336/EEC, DO NOT connect the wire which is coloured GREEN &
93/68/EEC and 73/23/EEC. YELLOW or GREEN.
2
Table of Contents
Welcome to LG
Thank you for buying this LG video cassette recorder Model LV900/LV800/LV803/LV703.
Description 2-5 Advanced Operations 21 - 32
Precautions & plug wiring 2 Instant Timer Recording (ITR) 21 - 22
Remote Control Location & function 4 VIDEO Plus+ Recording
Your VCR's Controls 5 (LV900/LV800/LV803) 23 - 24
Timer Recording using On Screen
Setting Up 6 - 16
Connecting to a TV & Satellite 6 Display 25- 26
Connecting to a Hi-Fi & Camcorder 7 Energy Saving 27
Tuning in a video channel on your TV 8 - 9 On Screen Display 27
How to use the main menu 10 Tape Counter Memory Stop 28
Using your VCR for the very first time 11 Child Lock 28
Tuning in TV Stations Automatically 12 Wide Screen Compatibility (16:9) 29
Tuning in TV Stations Manually 13 - 14 Automatic Memory Power Shut-Off 30
Changing the order of TV Stations 15 Video Doctor (Self-Diagnosis) 30
Deleting & Selecting TV Stations 16 Hi-Fi Stereo Sound System 31
Basic Operations 17 - 20 ez (easy) operations 32
Playing a tape 17 - 18
Helpful Hints 33 - 34
Setting the Colour System 19
Tape Copying 33
Setting the Clock Manually 20
Specifications 33
Troubleshooting Check List 34
3
Remote Control
Location & Function
Your video recorder (VCR) is designed so that almost all of its features can be controlled from the
REMOTE CONTROL HANDSET. Some features can also be controlled from the FRONT PANEL
of the video recorder. The maximum operating distance that you may control your video recorder
is about 7.5 metres (25 feet). It must also be within an angle of 30 degrees either side of the
REMOTE SENSOR on the front of your video recorder.
To avoid damage from possible battery leakage, remove the batteries if you do not plan to use the remote
control handset for an extended period of time. Do not use batteries of differing age or type. Always discard
batteries safely.
TV/VCR AUDIO/VIDEO MODE
VCR; to monitor, view playback or Select input source for recording
view the VCR's tuner EJECT
TV; to watch TV or view another Ejects tape
programme while recording CHILD LOCK
another programme Switches the Child Lock on and
POWER off
Switches the VCR on and off ez POWER OFF
Numbered buttons (see p. 32)
To select channels. ez REPEAT
Programme number information on (see p. 32)
To install batteries:
screen. LP
Your REMOTE CONTROL To select the recording speed of
HANDSET is powered by CM SKIP the tape
two AA type batteries. To fast forward picture search
a
1. To insert them, push through 30 seconds of a recording Feature is not available.
the tab backwards and i REC/ITR
lift off the cover of the Displays on screen menu Starts instant recording
handset. PLAY
2. Put the two batteries REW
into the compartment Rewinds the tape To play the tape
making sure the + and Reverse high speed picture play FF
