Image preview - the first page of the document
>> Download 93XXC-OM-E23 documenatation <<Text preview - extract from the document ( $SSHQGL[ ( $6&,, :DYHIRUP ([SRUW
8VLQJ $6&,,6WRUHG )LOHV
The ASCII waveform storage feature allows waveforms to be
stored to a mass-memory device in any of three ASCII
formats: Spreadsheet, Mathcad and MATLAB. Each format is
tailored for a commonly used analysis package. The user-
interface changes supporting ASCII waveform storage are
found in the STORE menu (see Chapter 13).
The table below summarizes the three formats' basic layout.
Examples of the use of each format are given on the following
pages.
Format Header Time Amplitude Sequence Multi- Dual Array
Format Values Values Times Segment Format allows
includes some Format stores Format stores Header Format dual-array
form of time values amplitude contains concatenates data (i.e.
header before with each values sequence time multiple Extrema, or
the data amplitude information for segments of a complex FFT)
value each sequence sequence to be stored
segment waveform
Spreadsheet Yes Yes Yes Yes Yes Yes
Mathcad Yes Yes Yes Yes Yes Yes
MATLAB No No Yes No Yes No
1RWH Once stored in ASCII, waveforms cannot be recalled
into the DSO.
(
