Image preview - the first page of the document
>> Download prestigio_geovision_pmp5597d_duo_service_manual documenatation <<
Text preview - extract from the document
Prestigio
GEOVISION
PMP5597D_DUO
TECHNICAL
SERVICE MANUAL
Prestigio
Product Specification
Model:PMP5597D_DUO
Features:
1. CPU: RockChip 3066 Duo Core ARM Cortex-A9
2. Screen:9.7" 1024*768 pixels
3. CTP: G+G
4. 1GB DDR3, 8GBFLASH; optional: 16 GB FLASH
5. WIFI: IEEE 802.11b/g/n
6. Dual camera:2M front camera and 2M rear camera
7. HDMI 1.4 TYPE-C
8. 3D G-Sensor
9. USB OTG
10. Battery: 7000mAh
Specification:
Hardware
RockChip 3066 Duo Core ARM Cortex-A9 + HD video
CPU
codec + 3D graphic accelerator
8GB MLC
Flash
Optional: 16GB MLC
Memory
RAM 1GB DDR3
TF CARD Support 2/4/8/16/32GB TF Card
Size
9.7' TFT
(Diagonal)
LCD
Aspect Ratio 4:3
Resolution 1024*768 pixels
Touch Panel Capacitive touch panel(G+G, Support 10 points touch)
Key Power, Reset, Volume+/-, Home
1/2
Prestigio
Front: 2million pixels
Camera
Rear: 2 million pixels
Audio Recording
Earphone Via microphone
Speaker 3.5mm stereo earphone
USB
USB 2.0 OTG 1W@8 x2
WIFI Support IEEE 802.11b/g/n transport protocol
G-Sensor Support 3D accelerometer game
AVI H.264, DIVX, DIVX, XVID, rm, rmvb, WMV, MOV, MP4
H.264, MPEG, DIVX, XVID), DATVCD), VOBDVD),
Video Decoding
MPEG, MPG, FLVH.263H.264), ASF, TS, TP, 3GP, MPG
etc
MP3,WMA,MP2,OGG,AAC,M4A,MA4,FLAC,APE,3GP,WA
Audio Decoding
V
Video Container MKV, MP4, AVI, RV/RMVB, VOB, WMV, MPG, TS etc
Picture Format JPG, JPEG, GIF, BMP, PNG
HDMI Support HDMI 1.4 protocol, TYPE-C
Battery 7000mAh
System Update Via TF card and OTA
Logo Update Via TF card
Certification & Regulation CE, FCC, and RoHS compliant
Physical Characteristics Dimension
Humidity Storage
Operating System
Operation 0~50◦ Jabse Service Manual Search 2025 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
