Image preview - the first page of the document
>> Download AZ5130_ET-SB-EX-BA-SI_1219296881 documenatation <<
Text preview - extract from the document
VCD MP3 CD Soundmachine
AZ 5130
all versions
VIDEO CD
TABLE OF CONTENTS
Handling Chip Components and Safety ..........................1 - 1 VCD Board And LCD Board
Circuit Diagram .......................................................8 - 1
Technical Specification & Service tools...........................2 - 1 Layout Diagram(LCD Board) ..................................8 - 2
Service Measurement......................................................2 - 2 Layout Diagram(VCD Board) .......................8 - 3 to 8-4
Connections and controls.....................................3 - 1 to 3- 2 Tape Board
Instructions for Use .............................................3 - 3 to 3 - 8 Circuit Diagram........................................................9 - 1
Layout Diagram .......................................................9 - 2
Disassembly Diagram......................................................4 - 1
Pin-description of ICs ..........................................4 - 2 to 4 - 5 Exploded Views Diagram
Cabinet ..............................................................10 - 1
Block Diagram .................................................................5 - 1 Tape Deck .........................................................10 - 2
Wiring Diagram ................................................................6 - 1
Mechanical Partslist.......................................................10 - 2
Tuner And Power Amplifier Board Electrical Partslist ............................................11 - 1 to 11 - 2
Circuit Diagram........................................................7 - 1
Layout Diagram .......................................................7 - 2
Radio Alignment ......................................................7 - 2
CLASS 1
