Image preview - the first page of the document
>> Download hfe_philips_az5741_service_en documenatation <<
Text preview - extract from the document
DVD 4W CD Soundmachine AZ5741/55/93/98/79
CONTENTS
Technical Specification......................................................................1-1..1-5
Safety Instruction......................................................................................2-1
Version Variation.......................................................................................2-2
Block diagram...........................................................................................3-1
Wiring diagram ........................................................................................3-2
Circuit Diagram
All PCB board......................................................................................4-1 4-5
Layout diagram
All PCB Layout....................................................................................5-1 5-6
Explode Drawing.......................................................................................6-1
Published by LZ 1209 Subject to modification 3141 785 37561
Version 1.1
1-1
TECHNICAL SPECIFICATION
Description Pos. Description Pos.
1 HANDLE
2 CD DOOR
3 TUNING KNOB
4 TUNER LENS
5 TOP CABINET
6 FRONT CABINET
7 SPEAKER GRILL(RIGHT)
8 VOL KNOB
9 ZOOM KNOB
10 USB COVER
11 STOP KNOB
12 MODE KNOB
13 KNOB RING
14 FUNCTION CONTROL
15 SPEAKER GRILL(LEFT)
16 IR SENSOR
17 DISPLAY LENS
18 FUNCTION MODE KNOB
19 ANTENNA
Battery location
NA
CABINET
Material: ABS/HIPS
Dimensions with Boxes 390 x 240 x 160mm (LxWxH) 42
Dimensions without Boxes: 454 x 275 x 200 mm (LxWxH) Finishing: 43
Weight (including packing): 3.98 kg Unit in Mastercarton: N/A 44
Weight (excluding packing and batteries): 3.05 kg Units in Dealercarton: 1 set 45
INTERCONNECTION POSSIBILITIES
Pos. Connection/Function Connector type Electrical data (input or R.O.P
27 AV Out Jack
28 Headphone Jack
29 AC JACK
ACCESSORIES :
(1) Remote Control
(2) AC Cord
(3) AV Cable
1-2
TECHNICAL SPECIFICATION
GENERAL DESCRIPTION
DVD PLAYER/ Digital Tuner /CASSETTE RECO(Per Channel 2W )
LIFE TIME(according to XUT-0026)
5 Years
PERFORMANCE CLASSES
Class Tuner Supply+Amplifier Loudspeaker Boxes Cassette Recorder DVD/CD
I X X X
II X
III
SAFETY requirements
See Sh-190-05
RADIATION/IMMUNITY requirements(EMC)
See Sh-190-05
CLIMATIC requirements(according to UAN-D1590)
ALL climates : till +35
MODERATE climates : NA till
POWER SUPPLY MAINS (AC)
Version /98 /93 /55
