Image preview - the first page of the document



>> Download hfe_philips_az1019_service_en documenatation <<

Text preview - extract from the document

CD Stereo Radio Recorder                                                                                 AZ1019




For repair information, we refer to manual AZ1018 (3140 785 22540), except the following mechanical parts
in different colour or printings :


401      3140 117 63870      Cassette Door Assy
403d     3140 117 63880      Front Cabinet Grille Assy
407      3140 114 45710      Knob DBB
422      3140 114 45690      Tray CD
426      3140 114 45700      Door CD

429      3140 114 45720      Handle




                                                                                                     CLASS 1
                                                                                                  LASER PRODUCT



                                                                        Subject to modification        GB   3140 785 32080
