Image preview - the first page of the document
hfe_philips_az1011_1012_1013_service_en


>> Download hfe_philips_az1011_1012_1013_service_en documenatation <<

Text preview - extract from the document
CD Stereo Radio Recorder                                            AZ1011, AZ1012, AZ1013




For repair information, we refer to manual AZ1008 (3140 785 22520), except the following
mechanical parts in different colours :



TABLE OF DIFFERENT MECHANICAL PARTS

                                                           AZ1011           AZ1012                AZ1013
 ITEM         ARTICLE DESCRIPTION         AZ1008
                                                           (BLUE)          (GREEN)             (BURGUNDY)
  3     CASSETTE DOOR                  9965 000 07504   9965 000 08419   9965 000 08419       3140 114 39170
  4     CASSETTE DOOR LENS             9965 000 07479   9965 000 07479   9965 000 07479       9965 000 07479
  21    HANDLE HINGE ADAPTOR (L)       9965 000 07487   9965 000 08409   9965 000 08422       3140 114 41130
  26    HANDLE HINGE ADAPTOR (R)       9965 000 07488   9965 000 08410   9965 000 08423       3140 114 41140
  27    TUNING KNOB                    9965 000 07489   9965 000 08411   9965 000 08411       9965 000 08411
  28    VOLUME KNOB                    9965 000 07490   9965 000 08412   9965 000 08412       9965 000 08412
  29    SELECTOR KNOB                  9965 000 07491   9965 000 08413   9965 000 08413       9965 000 08413
  30    REPEAT/PROGRAM KEY             9965 000 07492   9965 000 08414   9965 000 08414       9965 000 08414
  31    PLAY/STOP/FF/REW KEY           9965 000 07493   9965 000 08415   9965 000 08415       9965 000 08415
  32    DBB KNOB                       9965 000 07494   9965 000 07494   9965 000 07494       9965 000 07494
  41    HANDLE                         9965 000 07501   9965 000 08416   9965 000 08424       3140 114 41120
  42    BATTERY DOOR                   9965 000 07502   9965 000 08417   9965 000 08425       3140 114 41160
  48    CD DOOR                        9965 000 07503   9965 000 08418   9965 000 08426       3140 114 41180




                                                                                                      CLASS 1
                                                                                                   LASER PRODUCT



                                                                         Subject to modification          GB   3140 785 22660

PCS 107 335
