Image preview - the first page of the document
service


>> Download service documenatation <<

Text preview - extract from the document
Micro System                                                                                                                      BTB1370/12




                                   TABLE OF CONTENTS
                                                                                                   Chapter
                                   Location of PC Boards & Versions Variation .......................... 1
                                   Technical Specifications......................................................... 2
                                   Safety instruction.....................................................................3

                                   Set Block Diagram...................................................................4

                                   Set Wiring Diagram .................................................................5
                                    Disassembly Diagram .............................................................6
                                   Main Board...............................................................................7
                                     Circuit Diagram ................................................................7-1
                                     Layout Diagram................................................................7-2
                                   Display Board............................................................................8
                                      Circuit Diagram................................................................8-1
                                       Layout Diagram ..............................................................8-2
                                   Mechanical Exploded View ..................................................... 9
                                   Trouble Shooting....................................................................10
                                   Software Upgrade & Procedure To Restore Product Setting....11
                                   Revision list ............................................................................12



                 5 Gibson


Gibson
               Gibson

                                                                                                                                  3140 038 63220
Published by Xu & Sam wk1526 Subject to modification


Version1.0
     2. Technical Specification
TEST CONDITIONS:
1.POWER SUPPLY: AC.Accordiing to Ver
2.REF OUTPUT: 410W , Sound effect off
3.FM MONO: 22.5KHz Dev,1KHz MODULATION ,75 IMPEDANCE ,60dBu
4.FM STEREO : MAIN+SUB = 50KHz, PILOT : 10KHz,COMPOSITE: 40.0KHz
FM SECTION
                                                                                   TEST DATA
NO                      TEST ITEMS                          UNIT   NOM. LIMIT
                                                                                   1#      2#
                                                                          87.5    87.5    87.5
 1             Fvequency Range                              MHz
                                                                          108     108     108
                                                     88             18     22      18      18
 2        26dB QUENTING SENSITIVITY                  98     dB      18     22      18      18
                                                     107            18     22      20      19
 3            -3dB LIMITING POINT                    98     dB      20     26       9      10
 4           IF REJECTION 98MHZ                      98     dB      65     60     >126    >126
 5          IMAGE REJECT 98MHZ                       107    dB      30     25     >126    >126
 6                     S/N                          MONO            65     60      72      72
 7          OVERALL DISTERTION                               %      2       3     0.13    0.12
 8             MODULATION HUM                 10%THD S/N    dB      50     45      73      72
                                                88MHz       dBf     28     36      33      33
 9               TUNING SENS                    98MHz       dBf     28     36      35      35
                                                107MHz      dBf     28     36      35      35
10       STREO CHANNEL SEPARATION                1KHZ       Db      30     26      41      42
11            THD 10% POWER                      1KHZ       W       10
